DIAGNOSTIC PROCEDURE
Note. DTCs will be recorded at various operating times and conditions. Some DTCs require operation of sensor or switch for 5 seconds, while other components require operation for 5 minutes or longer at normal operating temperature, vehicle speed, and load. Therefore, some DTCs may not set in a service bay, and may require road testing to duplicate the conditions under which the code will set.
Diagnosis of computerized engine control system should be performed in the following order
- Ensure all mechanical engine systems other than computerized systems (i.e., compression, ignition, etc.) are operating properly. DO NOT proceed with testing unless all other problems have been repaired. If MIL is on, see «RETRIEVING DIAGNOSTIC TROUBLE CODES»(ref-3130-S19621668472000041800000) . For diagnosing hard codes, see appropriate DTC IDENTIFICATION table under «DIAGNOSTIC TROUBLE CODE DEFINITIONS»(ref-3130-S07902322592000041800000) to determine the probable cause of malfunction.
- For diagnosing intermittent codes, proceed to INTERMITTENTS in «TROUBLE SHOOTING - NO CODES»(ref-3137) article. Inspect condition of system harness by performing recommended voltage or continuity checks. See appropriate wiring diagram in «WIRING DIAGRAMS»(ref-3147) article for information on specific circuit configuration. Inspect condition of individual components. Repair or replace components as needed.
- Recheck system operation after repair is completed. If DTC still exists, substitute known-good ECM, then retest system. Verify system is repaired. After repairs have been completed, clear DTC(s). See «CLEARING DIAGNOSTIC TROUBLE CODES»(ref-3130-S23540189222000041800000) .
RETRIEVING DIAGNOSTIC TROUBLE CODES
Note. For specific scan tool operating procedures, see the scan tool manufacturer's instruction manual.
- Before entering on-board diagnostics, see «SERVICE PRECAUTIONS»(ref-3130-S33293560652000041800000). Turn ignition off. Locate Data Link Connector (DLC) under left side of instrument panel, and connect scan tool. (Scheme 30)
- Operate scan tool according to manufacturer's instructions. Read and record scan tool self-diagnostic output (stored codes). See «DIAGNOSTIC TROUBLE CODE (DTC) DEFINITIONS»(ref-3130-S07902322592000041800000). To perform testing for retrieved codes, see appropriate SELF-DIAGNOSTICS article.
Scheme 30
DIAGNOSTIC TROUBLE CODE DEFINITIONS
See DTC IDENTIFICATION (ACCENT, ELANTRA & TIBURON) or DTC IDENTIFICATION (SONATA) table or refer to appropriate DTC IDENTIFICATION table in appropriate SELF-DIAGNOSTICS article. Once DTC has been identified, proceed to appropriate diagnostic procedure in appropriate SELF-DIAGNOSTICS article. Repair condition which set DTC(s), beginning with lowest number first, then in ascending order.
Note. Not all codes apply to all models.
| Code | Probable Cause |
|---|---|
| P0102 | Mass Airflow (MAF) Circuit Input Low |
| P0103 | Mass Airflow (MAF) Circuit Input High |
| P0112 | Intake Air Temperature (IAT) Circuit Input Low |
| P0113 | Intake Air Temperature (IAT) Circuit Input High |
| P0116 | Engine Coolant Temperature (ECT) Sensor Range |
| P0117 | Engine Coolant Temperature (ECT) Sensor Input Low |
| P0118 | Engine Coolant Temperature (ECT) Sensor Input High |
| P0121 | Throttle Position (TP) Sensor Range |
| P0122 | Throttle Position (TP) Sensor Input Low |
| P0123 | Throttle Position (TP) Sensor Input High |
| P0128 (1) | Thermostat Malfunction |
| P0130 | HO2S Circuit Malfunction (Front) |
| P0131 | HO2S Circuit Voltage Low (Front) |
| P0132 | HO2S Circuit Voltage High (Front) |
| P0133 | HO2S Circuit Slow Response (Front) |
| P0134 | HO2S Circuit No Activity (Front) |
| P0135 | HO2S Heater Circuit Malfunction (Front) |
| P0136 | HO2S Circuit Malfunction (Rear) |
| P0137 | HO2S Circuit Voltage Low (Rear) |
| P0138 | HO2S Circuit Voltage High (Rear) |
| P0141 | HO2S Heater Circuit Malfunction (Rear) |
| P0201 | Injector No. 1 Circuit Malfunction |
| P0202 | Injector No. 2 Circuit Malfunction |
| P0203 | Injector No. 3 Circuit Malfunction |
| P0204 | Injector No. 4 Circuit Malfunction |
| P0300 | Random Misfire Detected |
| P0301 | Cylinder No. 1 Misfire Detected |
| P0302 | Cylinder No. 2 Misfire Detected |
| P0303 | Cylinder No. 3 Misfire Detected |
| P0304 | Cylinder No. 4 Misfire Detected |
| P0326 | Knock Sensor Range |
| P0335 | Crankshaft Position (CKP) Sensor Malfunction |
| P0336 | Crankshaft Position (CKP) Sensor Range |
| P0342 | Camshaft Position (CMP) Sensor Input Low |
| P0343 | Camshaft Position (CMP) Sensor Input High |
| P0422 | Main Catalyst Efficiency Below Threshold |
| P0441 | EVAP Purge Valve Permanently Open |
| P0442 | EVAP System Leak Detected |
| P0443 (2) | EVAP System Purge Control Valve Circuit Malfunction |
| P0444 | EVAP System Purge Control Valve Circuit Open |
| P0445 | EVAP System Purge Control Valve Circuit Shorted |
| P0446 (2) | EVAP Vent Control Valve Malfunction |
| P0447 (2) | EVAP Vent Valve Short To Ground |
| P0448 (2) | EVAP Vent Valve Short To Voltage |
| P0451 (2) | Fuel Tank Pressure Sensor Signal Not Plausible |
| P0452 (2) | Fuel Tank Pressure Sensor Signal Low |
| P0453 (2) | Fuel Tank Pressure Sensor Signal High |
| P0455 | EVAP System Incorrect Purge Flow |
| P0501 | Vehicle Speed Sensor (VSS) Range |
| P0506 | Idle RPM Lower Than Expected |
| P0507 | Idle RPM Higher Than Expected |
| P0562 (1) | System Voltage Low |
| P0563 (1) | System Voltage High |
| P0606 (1) | Internal Control Module ROM Error |
| P1123 | Long Term Fuel Trim Additive Air, System Too Rich |
| P1124 | Long Term Fuel Trim Additive Air, System Too Lean |
| P1127 | Long Term Fuel Trim Multiplicative, System Too Rich |
| P1128 | Long Term Fuel Trim Multiplicative, System Too Lean |
| P1401 (1) | DM-TL System Malfunction |
| P1402 (1) | DM-TL Motor Malfunction |
| P1403 (1) | DM-TL Valve Malfunction |
| P1510 | Idle Control Valve Opening Coil Circuit Shorted |
| P1513 | Idle Control Valve Opening Coil Circuit Open |
| P1552 | Idle Control Valve Closing Coil Circuit Shorted |
| P1553 | Idle Control Valve Closing Coil Circuit Open |
| P1586 (1) | Transmission Encoding Signal Not Rational |
| P1605 | Rough Road Sensor Circuit Malfunction |
| P1606 | Rough Road Sensor Signal Not Rational |
| P1611 | MIL Request Signal Circuit Input Low |
| P1613 | MIL Request Signal Circuit Input High |
| (1) Accent only. (2) Elantra and Tiburon only. | |
| (1) | Accent only. |
| (2) | Elantra and Tiburon only. |
DTC IDENTIFICATION (ACCENT, ELANTRA & TIBURON)
| Code | Probable Cause |
|---|---|
| P0100 | Mass Airflow (MAF) Circuit Malfunction |
| P0101 (1) | Mass Airflow (MAF) Range/Performance Malfunction |
| P0110 | Intake Air Temperature (IAT) Circuit Malfunction |
| P0115 | Engine Coolant Temperature (ECT) Sensor Circuit Malfunction |
| P0120 | Throttle Position Circuit Malfunction |
| P0121 (1) | Throttle Position (TP) Sensor Range/Performance |
| P0125 | Insufficient Coolant Temperature For Closed Loop |
| P0130 (2) | HO2S Circuit Malfunction (Front) |
| P0130 (1) | HO2S Circuit Malfunction (Bank 1, Sensor 1) |
| P0133 (1) | HO2S Circuit Slow Response (Bank 1, Sensor 1) |
| P0134 (1) | HO2S Circuit No Activity (Bank 1, Sensor 1) |
| P0135 (1) | HO2S Heater Circuit Malfunction (Bank 1, Sensor 1) |
| P0135 (2) | HO2S Heater Circuit Malfunction (Front) |
| P0136 (1) | HO2S Circuit Malfunction (Bank 1, Sensor 2) |
| P0136 (2) | HO2S Circuit Malfunction (Rear) |
| P0140 (1) | HO2S No Activity Detected (Bank 1, Sensor 2) |
| P0141 (2) | HO2S Heater Circuit Malfunction (Rear) |
| P0141 (1) | HO2S Heater Circuit Malfunction (Bank 1, Sensor 2) |
| P0150 (1) | HO2S Circuit Malfunction (Bank 2, Sensor 1) |
| P0153 (1) | HO2S Circuit Slow Response (Bank 2, Sensor 1) |
| P0154 (1) | HO2S Circuit No Activity (Bank 2, Sensor 1) |
| P0155 (1) | HO2S Heater Circuit Malfunction (Bank 2, Sensor 1) |
| P0156 (1) | HO2S Circuit Malfunction (Bank 2, Sensor 2) |
| P0160 (1) | HO2S No Activity Detected (Bank 2, Sensor 2) |
| P0161 (1) | HO2S Heater Circuit Malfunction (Bank 2, Sensor 2) |
| P0170 (1) | Fuel Trim Malfunction (Bank 1) |
| P0173 (1) | Fuel Trim Malfunction (Bank 2) |
| P0201 | Injector No. 1 Circuit Malfunction |
| P0202 | Injector No. 2 Circuit Malfunction |
| P0203 | Injector No. 3 Circuit Malfunction |
| P0204 | Injector No. 4 Circuit Malfunction |
| P0205 (1) | Injector No. 5 Circuit Malfunction |
| P0206 (1) | Injector No. 6 Circuit Malfunction |
| P0230 (1) | Fuel Pump Circuit Malfunction |
| P0300 (2) | Random Misfire Detected |
| P0301 | Cylinder No. 1 Misfire Detected |
| P0302 | Cylinder No. 2 Misfire Detected |
| P0303 | Cylinder No. 3 Misfire Detected |
| P0304 | Cylinder No. 4 Misfire Detected |
| P0305 (1) | Cylinder No. 5 Misfire Detected |
| P0306 (1) | Cylinder No. 6 Misfire Detected |
| P0325 (2) | Knock Sensor Circuit Malfunction |
| P0325 (1) | Knock Sensor No. 1 Circuit Malfunction |
| P0330 (1) | Knock Sensor No. 2 Circuit Malfunction |
| P0335 | Crankshaft Position (CKP) Sensor Malfunction |
| P0340 | Camshaft Position (CMP) Sensor Malfunction |
| P0350 (1) | Ignition Coil Primary/Secondary Circuit Malfunction |
| P0351 (1) | Ignition Coil "A" Primary/Secondary Circuit Malfunction |
| P0352 (1) | Ignition Coil "B" Primary/Secondary Circuit Malfunction |
| P0353 (1) | Ignition Coil "C" Primary/Secondary Circuit Malfunction |
| P0354 (1) | Ignition Coil "D" Primary/Secondary Circuit Malfunction |
| P0355 (1) | Ignition Coil "E" Primary/Secondary Circuit Malfunction |
| P0356 (1) | Ignition Coil "F" Primary/Secondary Circuit Malfunction |
| P0400 (2) | EGR Flow Malfunction |
| P0403 (2) | EGR Solenoid Circuit Malfunction |
| P0420 (1) | Catalyst Efficiency Below Threshold (Bank 1) |
| P0421 (2) | Catalyst Efficiency Below Threshold |
| P0430 (1) | Catalyst Efficiency Below Threshold (Bank 2) |
| P0440 (1) | EVAP Control System Malfunction |
| P0442 | EVAP System Small Leak Detected |
| P0443 | EVAP Purge Control Valve Circuit Malfunction |
| P0446 | EVAP Vent Control Malfunction |
| P0450 | EVAP Fuel Tank Pressure Sensor Malfunction |
| P0451 (1) | EVAP Fuel Tank Pressure Sensor Signal Range/Performance |
| P0452 (2) | EVAP Fuel Tank Pressure Sensor Low Input |
| P0453 (2) | EVAP Fuel Tank Pressure Sensor High Input |
| P0455 | EVAP System Large Leak Detected |
| P0500 (1) | OBD-II Rough Road Detection, Vehicle Speed Malfunction From ABS/TCS Or RF Wheel Sensor |
| P0500 (2) | Vehicle Speed Sensor (VSS) Malfunction |
| P0505 (1) | Idle Speed Control (ISC) Actuator Mechanical Malfunction |
| P0505 (2) | Idle Control System Malfunction |
| P0506 (1) | Idle RPM Lower Than Expected |
| P0507 (1) | Idle RPM Higher Than Expected |
| P0510 (2) | Closed Throttle Position Switch Malfunction |
| P0601 (1) | Internal Control Module ROM Check Sum Error |
| P1100 (2) | Manifold Absolute Pressure (MAP) Sensor Malfunction |
| P1134 (1) | HO2S Circuit Transition Switch Time Malfunction/Slop (Bank 1, Sensor 1) |
| P1154 (1) | HO2S Circuit Transition Switch Time Malfunction/Slop (Bank 2, Sensor 1) |
| P1166 (1) | HO2S Controller Adaptation Diagnosis Malfunction (Bank 1) |
| P1167 (1) | HO2S Controller Adaptation Diagnosis Malfunction (Bank 2) |
| P1168 (1) | HO2S Heater Power Incorrect (Bank 1, Sensor 2) |
| P1169 (1) | HO2S Heater Power Incorrect (Bank 2, Sensor 2) |
| P1372 (1) | Segment Time Acquisition Incorrect |
| P1440 (1) | EVAP Control System Vent Circuit Malfunction |
| P1443 (1) | EVAP Control System Fuel Tank Cap Missing |
| P1510 (1) | Idle Charge Actuator Command Signal Incorrect (Coil 1) |
| P1511 (1) | Idle Charge Actuator Command Signal Incorrect (Coil 2) |
| P1520 (2) | Generator FR Terminal Circuit Malfunction |
| P1521 (2) | Power Steering Pressure Switch Signal Malfunction |
| P1529 (1) | Customer Snapshot (MIL Request/Freeze Frame) Request VIA CAN |
| P1602 (1) | Serial Communication Problem With TCU (TIME-OUT) |
| P1613 (1) | ECM Self Test Failed |
| P1616 (1) | Main Relay Malfunction |
| P1623 (1) | Diagnostic Lamp Power Stage Malfunction |
| P1624 (1) | Cooling Fan Relay Circuit Malfunction (LOW Circuit) |
| P1625 (1) | Cooling Fan Relay Circuit Malfunction (HIGH Circuit) |
| (1) Sonata 2.5L only. (2) Sonata 2.4L only. | |
| (1) | Sonata 2.5L only. |
| (2) | Sonata 2.4L only. |
DIAGNOSTIC TROUBLE CODE IDENTIFICATION (SONATA)
CLEARING DIAGNOSTIC TROUBLE CODES
After testing and repairs have been completed, disconnect negative battery cable for at least 15 seconds to clear codes. A stored DTC will be cleared from ECM memory if the same malfunction is not detected for 40 drive cycles. On Sonata, fuel system rich/lean or misfire DTCs will be cleared when engine operating conditions are the same as when DTC was first detected and original malfunction is not detected during 80 drive cycles.
