# 1.6l turbo, automatic a/c circuit

# 1.6l turbo, automatic a/c circuit (1 of 3)

Air conditioning 1.6l turbo — 1.6l turbo, automatic a/c circuit — 1.6l turbo, automatic a/c circuit (1 of 3). Hyundai Sonata VII facelift (2017-2019)
Components on the diagram

    # 1.6l turbo, automatic a/c circuit (2 of 3)

    Air conditioning 1.6l turbo — 1.6l turbo, automatic a/c circuit — 1.6l turbo, automatic a/c circuit (2 of 3). Hyundai Sonata VII facelift (2017-2019)
    Components on the diagram

      # 1.6l turbo, automatic a/c circuit (3 of 3)

      Air conditioning 1.6l turbo — 1.6l turbo, automatic a/c circuit — 1.6l turbo, automatic a/c circuit (3 of 3). Hyundai Sonata VII facelift (2017-2019)
      Components on the diagram
