# Memory mirrors circuit, except hybrid

# Memory mirrors circuit, except hybrid (1 of 2)

Memory systems — Memory mirrors circuit, except hybrid — Memory mirrors circuit, except hybrid (1 of 2). Hyundai Sonata VII (2014-2017)

Components on the diagram

# Memory mirrors circuit, except hybrid (2 of 2)

Memory systems — Memory mirrors circuit, except hybrid — Memory mirrors circuit, except hybrid (2 of 2). Hyundai Sonata VII (2014-2017)

Components on the diagram
