Warning systems — Chime circuit, except hybrid Hyundai Sonata VI
All systems — 39 systems
- Air conditioning 2.0l 2
- Air conditioning 2.4l 2
- Air conditioning 2.4l hybrid
- Anti-lock brakes 2
- Anti-theft 4
- Body control modules 2
- Computer data lines 2
- Cooling fan 2.0l
- Cooling fan 2.4l
- Cooling fan 2.4l hybrid
- Cruise control 2.0l
- Cruise control 2.4l
- Cruise control 2.4l hybrid
- Defoggers 2
- Electronic power steering
- Engine performance 2.0l
- Engine performance 2.4l
- Engine performance 2.4l hybrid 3
- Exterior lights 4
- Ground distribution 2
- Headlights 2
- Horn 2
- Instrument cluster 2
- Interior lights 4
- Navigation 6
- Power distribution 2
- Power door locks 2
- Power mirrors 5
- Power seats 4
- Power top/sunroof 3
- Power windows 4
- Radio 9
- Shift interlock 2
- Starting/charging 5
- Supplemental restraints 2
- Transmission 2
- Trunk, tailgate, fuel door 2
- Warning systems 4
- Wiper/washer 2
Components on these wiring diagrams 19
Click a component to highlight it on every diagram it appears on.
