Back View Camera System - Except Hev: Overview Hyundai Sonata VI

Navigation System 5 illustrations ~136 words

Scheme 26

Scheme 26: COMPONENT LOCATION
Scheme 26: COMPONENT LOCATION

Scheme 27

Scheme 27: CIRCUIT DIAGRAM
Scheme 27: CIRCUIT DIAGRAM

Scheme 28

Scheme 28
Scheme 28

DESCRIPTION

Back view camera will activate when the backup light is ON with the ignition switch ON and the shift lever in the R position.

This system is a supplemental system that shows behind the vehicle through the AV monitor while backing-up.

WARNINGThis system is a supplementary function only. It is the responsibility of the driver to always check the inside/outside rearview mirror and the area behind the vehicle before and during backing up because there are blind spots that can't be seen through the camera.

Scheme 29

Scheme 29: Back View Camera
Scheme 29: Back View Camera
  1. Remove the screws, clip and trunk lid trim in the trunk. (Refer to the " «TRUNK LID»(ref-424779-S19642075942011100100000) ")
  2. Remove the trunk lid garnish.
  3. Remove the back view camera (A) after removing the connector and screws.

Scheme 30

Scheme 30: Back View Camera Unit
Scheme 30: Back View Camera Unit
  1. Disconnect the negative (-) battery terminal.
  2. Remove glove box housing. (Refer to " «CRASH PAD»(ref-424764-S23522138592011100100000) ")
  3. Remove the back view camera unit (A) after removing the nut and connector.
  1. Install the back view camera.
  2. Install the trunk lid garnish and trim.
