Lighting System - Except Hev: Specifications Hyundai Sonata VI

Exterior Lights 5 illustrations ~113 words

SPECIFICATION

ItemBulb Watt (W)
FrontHead lamp (High)55
Head lamp (Low)55
Turn signal lamp28
Position lamp8
Fog lamp35
RearStop lamp/Tail lamp28/8
Tail lamp5
Back up lamp16
Turn signal lamp27
License plate lamp5
High mounted stop lampLED
InteriorRoom lampMap lamp (Front)8
Room lamp (center)10
Map lamp (Rear)6
Trunk5
Sunvisor5

ITEM SPECIFICATION CHART

Scheme 206

Scheme 206: COMPONENT LOCATION
Scheme 206: COMPONENT LOCATION

Scheme 207

Scheme 207: Component
Scheme 207: Component

Scheme 208

Scheme 208: Removal
Scheme 208: Removal

Scheme 209

Scheme 209
Scheme 209

Scheme 210

Scheme 210
Scheme 210
  1. Disconnect the negative (-) battery terminal.
  2. Remove the front bumper. (Refer to the " «FRONT BUMPER»(ref-424788-S03592802032011100100000) ")
  3. Loosening the head lamp mounting bolts (3ea) and disconnect the head lamp connector. Then, remove the head lamp assembly (A). NOTE: Take care not to scratch the head lamp lens or fender. NOTE: Take care that holding clip (A) is not to be damaged.
  4. Remove the dust caps from the head lamp assembly after turning in the counter clock-wise direction. Head Lamp (High) Cap Head Lamp (Low) Cap Turn Signal Lamp
