LUBRICANTS
| Items | Specified Lubricant | Quantity |
|---|---|---|
| Steering column bearing | Multipurpose grease SAE J310a, NLGI No.2 | As required |
| Steering gear box rack, pinion gear part | Multipurpose grease SAE J310a, NLGI No.2 | As required |
| Bellows | Silicone grease | As required |
| Oil pump | Power steering fluid (PSF-4) | As required |
| Power steering fluid | Power steering fluid (PSF-4) | 1.0 lit (0.88 qts.) |
LUBRICANTS QUANTITY
CHECKING STEERING ANGLE
- Place the front wheel on a turning radius gauge and measure the steering angle. Standard value: Wheel angle Inside wheel 39.17°±2 Outside wheel 31.56°
- If the measured value is not within the standard value, adjust the toe and inspect again.
Scheme 21
Scheme 22
Scheme 23
- Disconnect tie rod and knuckle with the special tool (09568-A000).
- Shake the ball joint stud several times to check for looseness. Tie rod end ball joint starting torque: 30 kg.cm or less
- If the starting torque exceeds the upper limit of the standard value, replace the tie rod end.
- Even if the starting torque is below the lower limit of the standard value, check the play of the ball joint and replace if necessary.
CHECKING STEERING WHEEL RETURN
- The force required to turn the steering wheel and the wheel return should be the same for both moderate and sharp turns.
- When the steering wheel is turned 90° and held for a couple of seconds while the vehicle is being driven at 20-30 kph (12-19 mph), the steering wheel should return at least 20° from its central position when it is released.
Note. If the steering wheel is turned very quickly, steering may be momentarily difficult. This is not a malfunction because the oil pump output will be somewhat decreased.
Scheme 24
CHECKING POWER STEERING BELT TENSION
Refer to BELT, IDLER, BELT TENSIONER, PULLEY for 2.4L engines or INSPECTION for 3.3L engines .
