SPECIFICATIONS
| Items | Specifications |
|---|---|
| Rated voltage | DC 12 V |
| Operating temperature range | 30°C - +80°C (-22 ~ +176°F) |
| Rated load | |
| Dimmer & passing switch | High: 1A (Relay load) Low: 1A (Relay load) Passing: 1A (Relay load) |
| Lighting switch | Lighting: 1A (Relay load) |
| Turn signal & lane change switch | 6.6±0.5A (Lamp load) |
| Front fog lamp switch | 1A (Relay load) |
| Wiper & mist switch | Low, High: 4.5A (Motor load) Intermittent: 0.22±0.05A (Relay load) Lock: Max. 28A (Motor load) Mist: 4A (Motor load) |
| Washer switch | 4A (Motor load) |
| Variable intermittent volume switch | Max. 25mA |
SPECIFICATIONS
Scheme 1
Scheme 2
Scheme 3
Scheme 4
- Disconnect the negative (-) battery terminal.
- Remove the steering column upper and lower shrouds (A) after removing 3 screws.
- Remove the light switch (A) by pushing the lock pin (B) after disconnecting the connector.
- Remove the wiper switch (A) by pushing the lock pin (B) after disconnecting the connector.
- Installation is the reverse of removal.
