TIGHTENING TORQUE TABLE OF STANDARD PARTS
TIGHTENING TORQUE SPECIFICATION CHART Bolt nominal diameter (mm) Pitch (mm) Torque Nm (kg.cm, lb.ft) Head Mark 4 Head Mark 7 M5 0.8 3 ~ 4 (30 ~ 40, 2.2 ~ 2.9) 5 ~ 6 (50 ~ 60, 3.6 ~ 4.3) M6 1.0 5 ~ 6 (50 ~ 50, 3.6 ~ 4.3) 9 ~ 11 (90 ~ 110, 6.5 ~ 8.0) M8 1.25 12 ~ 15 (120 ~ 150, 9 ~ 11) 20 ~ 25 (200 ~ 250, 14.5 ~ 18.0) M10 1.25 25 ~ 30 (250 ~ 300, 18 ~ 22) 30 ~ 50 (300 ~ 500, 22 ~ 36) M12 1.25 35 ~ 45 (350 ~ 450, 25 ~ 33) 60 ~ 80 (600 ~ 800, 43 ~ 58) M14 1.5 75 ~ 85 (750 ~ 850, 54 ~ 61) 120 ~ 140 (1,200 ~ 1,400, 85 ~ 100) M16 1.5 110 ~ 130 (1,100 ~ 1,300,80 ~ 94) 180 ~ 210 (1,800 ~ 2,100, 130 ~ 150) M18 1.5 160 ~ 180 (1,600 ~ 1,800, 116 ~ 130) 260 ~ 300 (2,600 ~ 3,000, 190 ~ 215) M20 1.5 220 ~ 250 (2,200 ~ 2,500, 160 ~ 180) 360 ~ 420 (3,600 ~ 4,200, 260 ~ 300) M22 1.5 290 ~ 330 (2,900 ~ 3,300, 210 ~ 240) 480 ~ 550 (4,800 ~ 5,500, 350 ~ 400) M24 1.5 360 ~ 420 (3,600 ~ 4,200, 260 ~ 300) 610 ~ 700 (6,100 ~ 7,000, 440 ~ 505)
Scheme 1
Scheme 2
Note. The torques shown in the table are standard values under the following conditions: Nuts and bolts are made of galvanized steel bar. Galvanized plain steel washers are inserted. All nuts, bolts and plain washers are dry. The torques shown in the table are not applicable When spring washers, toothed washers and the like are inserted. If plastic parts are fastened. If self-tapping screws or self-locking nuts are used. If threads and surfaces are coated with oil. If you reduce the torques in the table to the percentage indicated below, under the following conditions, if will be the standard value. If spring washers are used: 85% If threads and bearing surfaces are stained with oil: 85%
LUBRICANTS CAPACITIES
Using any other type of parts and fluid can cause serious damaged if the vehicle. RECOMMENDED LUBRICANTS
| Description | 2.4 | 3.3 | |
|---|---|---|---|
| Engine oil | Oil pan | 3.7 (3.90, 3.26) | 5.5 (5.81, 4.84) |
| Oil filter | 0.3 (0.32, 0.26) | 0.4 (0.42, 0.35) | |
| Total | 4.0 (4.23, 3.52) | 5.2 (5.49, 4.58) | |
| Total | 4.0 (4.23, 3.52) | 6.4 (6.76, 5.63) | |
| Cooling system | 7.8 (8.2, 6.8) | 8.9 (9.40, 7.83) | |
| Manual transaxle | 2.15 (2.3, 1.86) | ||
| Automatic transaxle | 7.8 (8.2, 6.8) | 10.9 (11.51, 9.59) | |
| Power steering | 0.9 (0.95, 0.79) | 0.9 (0.95, 0.79) | |
| Capacities: [liter (U.S.q-s, lmp.qts)] | |||
LUBRICANTS CAPACITIES
Scheme 3
Scheme 4
Note. For best performance and maximum protection of all types of operation, select only those lubricants which
- Satisfy the requirements of the API classification.
- Have the proper SAE grade number for expected ambient temperature range. Lubricants which do not have both an SAE grade number and an API service classification on the container should not be used.
