Ignition Switch Hyundai Sonata V рестайлинг

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. Disconnect the negative (-) battery terminal.
2. Remove the crash pad side cover (A).
3. Remove the ignition switch (A) after loosening the screw and disconnecting the 6P connector.
4. Remove the steering column shaft (Refer to the «STEERING COLUMN / SHAFT»(ref-286587-S01008817922008060300000) ).
5. Remove the key warning switch and key illumination lamp (A) after loosening the screws and disconnecting the 6P connector.
6. If it is necessary to remove the key lock cylinder (A), Remove the key lock cylinder (A) after pushing lock pin (B) with key ON.
7. Installation is the reverse of removal procedure.

Scheme 5

1. Disconnect the ignition switch connector and key warning switch connector from under the steering column.
2. Check for continuity between the terminals.
3. If continuity is not specified, replace the switch.
