SPECIFICATION
| Items | Bulb Wattage (W) |
|---|---|
| Head lamp (High/Low) | 55/55 |
| Front turn signal lamp/Side marker | 28/8 |
| Front position lamp | 8 |
| Front fog lamp | 27 |
| Rear tail/stop lamp (Outside) | 28/8 |
| Rear tail lamp (Inner) | 8 |
| Back up lamp | 16 |
| Rear turn signal lamp | 27 |
| License plate lamp | 5 |
| Room lamp | 10 |
| Overhead console lamp | 10 x 2 |
| High mounted stop lamp | 16 |
| Glove box lamp | 5 |
| Luggage lamp | 5 |
| Door courtesy lamp | 5 |
| Vanity lamp | 5 |
| Rear side marker | 5 |
VOLTAGE SPECIFICATION CHART
Scheme 1
Scheme 2
- Disconnect the negative (-) battery terminal.
- Loose the mounting bolts (3EA) of head lamp.
- Remove the head lamp assembly after disconnecting the lamp connectors. NOTE: Take care that holding clip (A) is not to be damaged.
- Installation is the reverse of removal.
Scheme 3
- Pull out the head lamp relay (Low) (A) and head lamp relay (High) (B) from the engine compartment relay box.
- Check for continuity between terminals. There should be continuity between the No.1 and No.4 terminals when power and ground are connected to the No.2 and No.3 terminals.
- There should be no continuity between the No.1 and No.4 terminals when power is disconnected.
Scheme 4
