SPECIFICATIONS
| Items | Specifications |
|---|---|
| Rated voltage | DC 12V |
| Operating voltage | DC 9 ~ 16V |
| Operating temperature | 22°F~167°F(-30°C ~ 75°C) |
| Insulation resistance | 100Mohms or more |
| Dark current | Less than 5.5mA (12.8 V) - BCM & Receiver Less than 4mA (12.8V) - BCM |
| Rated load Burglar relay Horn relay Tail lamp relay security indicator Head lamp relay Rear defogger relay Power window timer relay Seat belt warning indicator (Driver/Assist) Key hole illumination lamp Room lamp Intermittent wiper relay DRL relay (For CANADA) Door lock relay Door unlock relay Hazard lamp relay Driver door unlock relay Trunk lid lock actuator | DC 12V, 200mA (Inductance load) DC 12V, 200mA (Inductance load) DC 12V, 200mA (Inductance load) DC 12V, 1W (LED load) DC 12V, 200mA (Inductance load) DC 12V, 200mA (Inductance load) DC 12V, 200mA (Inductance load) DC 12V, 1.2W (LED load) DC 12V, 2W (Lamp load) DC 12V, 21W (Lamp load) DC 12V, 200mA (Inductance load) DC 12V, 200mA (Inductance load) DC 12V, 200mA (Inductance load) DC 12V, 200mA (Inductance load) DC 12V, 200mA (Inductance load) DC 12V, 200mA (Inductance load) DC 12V, 200mA (Inductance load) |
SPECIFICATIONS
Scheme 1
Scheme 2
| Terminal No. | Connector A | Connector B | Connector C |
|---|---|---|---|
| 1 | B+ [For BCM] | Driver door key lock switch | Room lamp |
| 2 | IGN 1 | Driver door key unlock switch | |
| 3 | Alternator (L) | Central door key lock switch | Rear defogger relay |
| 4 | Key warning switch | Tail lamp switch | Tail lamp relay |
| 5 | Diagnosis | Intermittent wiper volume | Wiper relay |
| 6 | Over speed (Cluster) | Speed sensor | Door lock relay 1 |
| 7 | Crash unlock (Air bag) | Auto light switch | Door lock relay 3 |
| 8 | Driver door unlock switch | Driver seat belt switch | Horn relay |
| 9 | Assist door unlock switch | Head lamp switch | Hazard lamp relay |
| 10 | Rear left unlock switch | Assist door key unlock switch | Key hole illumination |
| 11 | Rear right unlock switch | Central door unlock switch | Driver seat belt indicator |
| 12 | Ground | Trunk key unlock switch | Ground |
| 13 | IGN 2 | Trunk open switch | |
| 14 | Washer switch | Auto light (Power) | |
| 15 | Intermittent wiper switch | Auto light (signal) | Safety power window ECU |
| 16 | Code saving | Auto light (Ground) | Power window relay |
| 17 | |||
| 18 | Rear defogger switch | Head lamp relay | |
| 19 | Seat belt reminder signal | Door lock relay 2 | |
| 20 | Driver door switch | Front fog lamp switch | |
| 21 | Assist door switch | Trunk lid open relay | |
| 22 | 4 door open switch | Start inhibit relay | |
| 23 | Trunk open switch | Security indicator | |
| 24 | Hood switch | Assist seat belt indicator |
BCM CONNECTOR TERMINALS REFERENCE
