IGNITION SYSTEM

ItemsSpecification
Ignition coilPrimary resistance0.62 ± 10 % (SI)
Secondary resistance7.0 ± 15 % (kohms)
Spark plugsUnleadedNGKIFR5G-11 (3.3L)
DENSOSK16PR-A11 (2.4L)
Gap1.0~1.1 mm (0.0394 ~ 0.0433 in.)

IGNITION SYSTEM SPECIFICATIONS

STARTING SYSTEM

ItemsSpecification
2.4L3.3L
StarterRated voltage12 V, 1.2 kW12 V, 1.4 kW
No. of pinion teeth88
No-load characteristicsVoltage11.5 V11.5 V
Ampere90A, MAX85A, MAX
Speed2,600 rpm, MIN2,600 rpm, MIN

STARTING SYSTEM SPECIFICATIONS

CHARGING SYSTEM

ItemsSpecification
2.4L3.3L
AlternatorTypeBattery voltage sensing<
Rate voltage13.5 V, 110A13.5 V, 130A
Speed in use1,000~ 18,000 rpm<
Voltage regulatorIC regulator built-in type<
Regulator setting voltage14.55 ± 0.2 V14.2 ~ 14.8 V
Temperature compensation3.5 ± 1 mV / °C4 ± 4 mV / °C
BatteryTypeMF 68AH<
Cold cranking amperage [at -18°C(-0.4°F)]600 A<
Reserve capacity110 min<
Specific gravity [at 20°C(68°F)]1.280 ± 0.01<

CHARGING SYSTEM SPECIFICATIONS

Note. COLD CRANKING AMPERAGE is the amperage a battery can deliver for 30 seconds and maintain a terminal voltage of 7.2V or greater at a specified temperature. RESERVE CAPACITY RATING is amount of time a battery can deliver 25A and maintain a minimum terminal voltage of 10.5V at 26.7°C(80.1°F).

AUTO CRUISE CONTROL SYSTEM

ItemsSpecification
Setting errorWithin ± 1.5Km/h on level road
Vehicle speed memory variationNo variation
Setting time0.1 sec max
Resuming time0.1 sec max.
Minimum operating speed40 ± 2Km/h
Cancel speed range15 ± 2Km/h
Maximum memorized speed160 ± 2Km/h
Pulling force127N(13Kgf)
Main switch serial resistance value3.9kohms ± 1%
Command switch serial resistance valueSET switch: 220ohms ± 1%
RESUME switch: 910ohms ± 1%

AUTO CRUISE CONTROL SYSTEM SPECIFICATIONS

SymptomSuspect areaRemedy
Engine will not start or is hard to start (Cranks OK)Ignition lock switchInspect ignition lock switch, or replace as required
Ignition coilInspect ignition coil, or replace as required
Spark plugsInspect spark plugs, or replace as required
Ignition wiring disconnected or brokenRepair wiring, or replace as required
Rough idle or stallsIgnition wiringRepair wiring, or replace as required
Ignition coilInspect ignition coil, or replace as required
Engine hesitates/poor accelerationSpark plugs and spark plug cablesInspect spark plugs / cable, or replace as required
Ignition wiringRepair wiring, or replace as required
Poor mileageSpark plugs and spark plug cablesInspect spark plugs / cable, or replace as required

IGNITION SYSTEM - TROUBLE SHOOTING CHART

SymptomSuspect areaRemedy
Charging warning indicator does not light with ignition switch "ON" and engine off.Fuse blownCheck fuses
Light burned outReplace light
Wiring connection looseTighten loose connection
Electronic voltage regulatorReplace voltage regulator
Charging warning indicator does not go out with engine running. (Battery requires frequent recharging)Drive belt loose or wornAdjust belt tension or replace belt
Battery cable loose, corroded or wornInspect cable connection, repair or replace cable
Electronic voltage regulator or alternatorReplace voltage regulator or alternator
WiringRepair or replace wiring
OverchargeElectronic voltage regulatorReplace voltage regulator
Voltage sensing wireRepair or replace wiring
DischargeDrive belt loose or wornAdjust belt tension or replace belt
Wiring connection loose or short circuitInspect wiring connection, repair or replace wiring
Electronic voltage regulator or alternatorReplace voltage regulator or alternator
Poor groundingInspect ground or repair
Worn batteryReplace battery

CHARGING SYSTEM - TROUBLE SHOOTING CHART

SymptomSuspect areaRemedy
Engine will not crankBattery charge lowCharge or replace battery
Battery cables loose, corroded or worn outRepair or replace cables
Transaxle range switch (Vehicle with automatic transaxle only)Refer to appropriate AUTOMATIC TRANSAXLE article
Fuse blownReplace fuse
Starter motor faultyReplace
Ignition switch faultyReplace
Engine cranks slowlyBattery charge lowCharge or replace battery
Battery cables loose, corroded or worn outRepair or replace cables
Starter motor faultyReplace
Starter keeps runningStarter motorReplace
Ignition switchReplace
Starter spins but engine will not crankShort in wiringRepair wiring
Pinion gear teeth broken or starter motorReplace
Ring gear teeth brokenReplace fly wheel or torque converter

STARTING SYSTEM - TROUBLE SHOOTING CHART

SPECIAL SERVICE TOOL

SPECIAL SERVICE TOOL REFERENCE Tool (Number and name) Illustration Use Alternator pulley remover wrench Removal and installation of alternator pulley

Scheme 28

Scheme 28: SPECIAL SERVICE TOOL

THE MICRO570 ANALYZER

The MICRO 570 Analyzer provides the ability to test the charging and starting systems, including the battery, starter and alternator.

CAUTIONBecause of the possibility of personal injury, always use extreme caution and appropriate eye protection when working with batteries.

Scheme 29

Scheme 29

KEYPAD

The MICRO 570 button on the key pad provides the following functions

Scheme 30

Scheme 30: KEYPAD

Scheme 31

Scheme 31: BATTERY TEST PROCEDURE

Scheme 32

Scheme 32

Scheme 33

Scheme 33

Scheme 34

Scheme 34

Scheme 35

Scheme 35
  1. Connect the tester to the battery. Red clamp to battery positive (+) terminal. Black clamp to battery negative (-) terminal. CAUTION: Connect clamps securely. If "CHECK CONNECTION" message is displayed on the screen, reconnect clamps securely.
  2. The tester will ask if the battery is connected "IN A VEHICLE" or "OUT OF A VEHICLE". Make your selection by pressing the arrow buttons; then press ENTER.
  3. Choose either CCA or CCP and press the ENTER button. NOTE: CCA: Cold cranking amps, is an SAE specification for cranking batteries at -1°C (0°F). CCP: Cold cranking amps, is an SAE specification for Korean manufacturer's for cranking batteries at -18°C (0°F).
  4. Set the CCA value displayed on the screen to the CCA value marked on the battery label by pressing up and down buttons and press ENTER. NOTE: The battery ratings(CCA) displayed on the tester must be identical to the ratings marked on battery label.
  5. The tester (Micro570) displays battery test results including voltage and battery ratings. A relevant action must be given according to the test results by referring to the battery test results as shown in the figure below. NOTE: The battery ratings (CCA) displayed on the tester must be identical to the ratings marked on battery label.
  6. To conduct starter test, continuously, press ENTER.
