Scheme 302

Scheme 303

COMPONENTS (2)

Scheme 304

COMPONENTS (3)

Scheme 305

COMPONENTS (4)

Scheme 306

Scheme 307

Scheme 308

Scheme 309

Scheme 310

Scheme 311

Scheme 312

Scheme 313

Scheme 314

Scheme 315

Scheme 316

Scheme 317

Scheme 318

Scheme 319

Scheme 320

Scheme 321

Scheme 322

Scheme 323

1. Remove the air duct.
2. Remove the battery.
3. Remove the battery tray (A).
4. Remove the air cleaner assembly (A) and PCM. (See «CYLINDER HEAD ASSEMBLY»(ref-286582-S01959040142008060300000) )
5. Disconnect the transaxle range connector (A).
6. Disconnect the input speed sensor, output speed sensor and vehicle speed sensor.
7. Disconnect the ground earth wire (A).
8. Remove the bolt (B) which mounts the clutch release cylinder (A) to the inhibitor switch.
9. Detach the clutch release cylinder (B) clip (A).
10. Detach the hoses (A), loosening the oil cooler hose clamps.
11. Using a engine-supporting tool, support the engine.
12. Remove the transaxle mounting bracket (A) bolts.
13. Remove the transaxle upper mounting bolts (A).
14. Remove the bolts which mount the transaxle to the front sub frame.
15. Lift up the vehicle.
16. Remove the under cover.
17. After removing the oil drain plug (A), drain the fluid.
18. Support the transaxle with a jack.
19. Remove the steering column bolt (See «STEERING COLUMN AND SHAFT»(ref-286587) ).
20. Remove the driveshaft (See «DRIVE-SHAFT»(ref-286599) ).
21. Remove the bolt (A) which mounts the transaxle to the rear sub-frame.
22. Remove the subframe.
23. Remove the transaxle lower mounting bolts from engine.
24. Remove the transaxle assembly.

Scheme 324

1. Attach the torque converter on the transaxle side and mount the transaxle assembly onto the engine. CAUTION: If the torque converter is mounted first on the engine, the oil seal on the transaxle may be damaged. Therefore, be sure to first assemble the torque converter to the transaxle.
2. Install the transaxle control cable (A) and adjust as follows. Move the shift lever and the transaxle range switch to the "N" position, and install the control cable. When connecting the control cable to the transaxle mounting bracket, install the clip until it contacts the control cable. Remove any free-play in the control cable by adjusting nut (B) and then check to see that the selector lever moves smoothly. Check to see that the control cable has been adjusted correctly.
3. Installation is the reverse of removal.

Scheme 325

Scheme 326

Scheme 327

Scheme 328

Scheme 329

Scheme 330

Scheme 331

1. Remove the center console cover (A) after disconnecting the connectors (3EA).
2. Remove the rear center console upper cover (A).
3. Remove the front center console upper cover (A).
4. Remove the center console. (Screw : 6EA)
5. Disconnect the sports mode connector (A).
6. Disconnect the control cable (A).
7. Remove the shift lever assembly (A) (Bolt : 4EA)

Scheme 332

Scheme 333

1. Adjusting method for T/M control cable Set room side lever and T/M side lever to "N" position. Connect room side lever and shift cable. Connect T/M side lever (A) to cable in the following order. Push cable (B) lightly to "F" direction shown to eliminate FREE PLAY of cable. Tighten adjusting nut. After adjusting according to (2)- (4). Check to be sure that this part operates surely at each range of T/M side corresponding to each position of room lever.
