Wiring diagram: Computer data lines 2.4l — 2.4l, computer data lines circuit Hyundai Sonata V

Components on these wiring diagrams 33

Click a component to highlight it on every diagram it appears on.

• ABS Control Module
• ABS Diagnosis
• Cruise Control Module
• Data Input/ Output
• Data Link Connector
• Electronic Power Steering Control Module
• Engine Compartment Junction Block
• Engine Control Relay
• Flash Source
• Fuel Sender, Fuel Pump Motor
• Fuse 17
• Fuse 24
• I/P-B
• I/P-E
• I/P-G
• I/P-K
• I/P-L
• Immobilizer Control Module
• Instrument — Cluster
• Joint Connector
• K Line
• Keyless Entry Control Module
• M/T A/T
• Multipurpose Check Connector
• On Strut Tower
• Passenger Compartment Junction Block
• Spark Timing A/T Vss In
• Spark Timing M/T
• SRS Control Module
• Sunroof Fuse
• Vehicle Speed Sensor
• Vss In
• W/O Immobilizer
