Power Windows: Overview Hyundai Sonata V

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. Remove the door window regulator handle and then remove clip using a piece of cloth (Manual type only).
2. Remove the quadrant inner cover and the rear view mirror.
3. Remove the front door inside handle housing.
4. Remove the front door trim panel.
5. Insert a trim panel remover between the trim fasteners and the door trim panel to pry off. Disconnect the door lamp connector.
6. Remove the pull handle mounting bracket, inside door handle and the door trim seal.
7. Remove the front speaker.
8. Remove the front door belt outside weatherstrip.
9. Lower the door window glass and loosen the carrier plate mounting bolts in the regulator channel. Tightening torque Front door glass mounting bolts: 8-12 Nm (80-120 kg.cm, 5.8-8.7 lb.ft)
10. Pull the door glass out through the window slot.
11. Remove the door regulator channel mounting bolts and then remove the door regulator assembly. Tightening torque Door regulator channel mounting bolts: 4-6 Nm (40-60 kg.cm, 2.9-4.4 lb.ft)
12. Installation is the reverse of removal. When installing the door trim seal, butyl tape should not be placed over the door trim fastener mounting area.

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Remove the door window regulator handle and then remove clip using a piece of cloth (Manual type only)
2. Remove the rear door inside handle housing.
3. Remove the 3 mounting screws from the rear door trim panel.
4. Insert a trim panel remover between the trim fasteners and the door trim panel to pry off. Disconnect the connector.
5. Remove the door pull handle mounting bracket and inside door handle.
6. Remove the door trim seal.
7. Lower the door glass and remove the door glass run and delta lower channel. Tightening torque Rear door glass mounting bolts: 8~12 Nm (80~120 kg.cm, 5.8~8.7 lb.ft) Delta lower channel mounting bolts: 8~12 Nm (80~120 kg.cm, 5.8~8.7 lb.ft)
8. Remove the carrier plate mounting bolts from the door regulator channel and remove the door glass.
9. Remove the door regulator channel mounting bolts and then remove the door regulator assembly. Tightening torque Door regulator channel mounting bolts: 4~6 Nm (40~60 kg.cm, 2.9~4.4 lb.ft)
10. Installation is the reverse of removal. When installing the door trim seal, butyl tape should not be placed over door trim fastener mounting area.
