Steering Column and Steering Shaft: Specifications Hyundai Sonata V

Steering Column 10 illustrations ~204 words

SPECIFICATIONS

ItemSpecification
Shaft and joint typeCollapsible, cross joint with tilt column
Steering gear typeRack and pinion
Rack stroke150 ± 1 mm
Oil pump typeVane type
Oil pump displacement9.6 cm 3 /rev. Max. (0.59 in 3 /rev, Max)

General Specifications

TIGHTENING TORQUE

ItemNmKg.cm
Steering column and shaft
Airbag module mounting bolt8 ~ 1180 ~ 100
Steering column to column member mounting (upper)13 ~ 18130 ~ 180
Steering column to column member mounting (lower)13 ~ 18130 ~ 180
Steering column member to cowl pad9 ~ 1490 ~ 140
Steering wheel lock nut40 ~ 50400 ~ 500
Joint assembly15 ~ 20150 ~ 200
Steering gear box
Pressure hose to gear box12 ~ 18120 ~ 180
Return tube to gear box12 ~ 18120 ~ 180
Tie rod to rack (MANDO)80 ~ 100800 ~ 1000
Tie rod end lock nut50 ~ 55500 ~ 550
Rack support plug lock nut (MANDO)50 ~ 70500 ~ 700
Pinion and valve assembly to self locking nut (MANDO)50 ~ 70500 ~ 700
End plug50 ~ 70500 ~ 700
Feed tubes12 ~ 18120 ~ 180
Tie rod end to knuckle24 ~ 34240 ~ 340
Mounting bracket to crossmember60 ~ 80600 ~ 800

Torque Specifications (1 Of 2)

ItemNmKg.cm
Oil pump
Pressure hose to oil pump (DOHC Engine)55 ~ 65550 ~ 650
Oil pump mounting bolt39 ~ 60390 ~ 600
Heat protector mounting bolt45 ~ 55450 ~ 550
Oil pump bracket mounting bolt39 ~ 60390 ~ 600
Pump cover to pump body21 ~ 29210 ~ 290
Suction connector to oil pump body13.6 ~ 18.4136 ~ 184
Flow control valve connector to pump body70 ~ 80700 ~ 800
Steering hoses and oil reservoir
Oil reservoir installation bolt4 ~ 640 ~ 60
Oil reservoir bracket mounting bolt4 ~ 640 ~ 60
Cooler tube clamp mounting bolt4 ~ 640 ~ 60
Tube clip and tube bracket4 ~ 640 ~ 60
Pressure hose bracket mounting bolt4 ~ 640 ~ 60
Hose clamp4 ~ 640 ~ 60

Torque Specifications (2 Of 2)

Scheme 1

Scheme 1: LUBRICANTS
Scheme 1: LUBRICANTS

Scheme 2

Scheme 2: COMPONENTS [NPS]
Scheme 2: COMPONENTS [NPS]

Scheme 3

Scheme 3: COMPONENTS [EPS]
Scheme 3: COMPONENTS [EPS]

Scheme 4

Scheme 4: REMOVAL
Scheme 4: REMOVAL

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Remove the driver's side air bag module (DAB) by using the hexagonal wrench.
  2. Disconnect the DAB and horn connector, and remove the steering wheel nut.
  3. Remove the steering wheel using the special tool (09561-11001). CAUTION: Do not hammer on the steering wheel to remove it; doing so may damage the collapsible mechanism.
  4. Remove the steering column lower and upper shrouds.
  5. Remove the lower crash pad panel.
  6. Remove the hood release lever and then disconnect the DLC (Data Link Connector).
  7. Remove the lower crash pad frame.
  8. Disconnect the connectors and remove the multifunction switch.
  9. Remove the bolt securing the coupling and universal joint. Pull out coupling and universal joint from the gear box.
  10. Remove the steering column mounting 4 bolts.
  11. Remove the steering column.

Scheme 9

Scheme 9: DISASSEMBLY
Scheme 9: DISASSEMBLY

Scheme 10

Scheme 10
Scheme 10
  1. Remove the coupling and universal joint from the steering column and shaft assembly.
  2. If it is necessary to remove the steering and ignition lock assembly, use a hack saw to cut the torsion bolt at the key holder assembly side.
