TROUBLESHOOTING (A/T)

(F4A42 MODEL)

Scheme 36

Scheme 36: TROUBLESHOOTING (A/T)

DIAGNOSIS FUNCTION

  1. Connect the Hi Scan Pro to the data link connector for diagnosis.
  2. Read the output diagnostic trouble codes. Then follow the remedy procedures according to the "DIAGNOSTIC TROUBLE CODE DESCRIPTION" on the following pages. NOTE: A maximum of 8 diagnostic trouble codes (in the sequence of occurrence) can be stored in the Random Access Memory (RAM) incorporated within the control module. The same diagnostic trouble code can be stored one time only. If the number of stored diagnostic trouble codes or diagnostic trouble patterns exceeds 8, already stored diagnostic trouble codes will be erased in sequence, beginning with the oldest. Do not disconnect the battery until all diagnostic trouble codes or diagnostic trouble patterns have been read out, because all stored diagnostic trouble codes or diagnostic trouble patterns will be cancelled when the battery is disconnected.
  3. If the fail-safe system is activated and the transaxle is locked in third gear, the diagnostic trouble code in the fail-safe code description will be stored in the RAM. Three of these diagnostic trouble codes can be stored.
  4. The cancellation will occur if, with the transaxle locked in third gear, the ignition key is turned to the OFF position, but the diagnostic trouble code is stored in the RAM.
  5. Memorization Up to 8 diagnosis items and 3 fail-safe items can be memorized. If the memory capacity is exceeded, diagnosis and fail-safe items in the memory are overwritten, starting with the oldest. No code can be memorized more than once.
  6. Diagnosis Code Deletion Automatic Deletion All diagnosis codes are deleted from memory the 200th time the ATF temperature reaches 50°C after memorization of the most recent diagnosis code Forced Deletion Memorized diagnosis codes can be deleted using the scan-tool, provided the following conditions are satisfied: The ignition switch is ON. There is no detection pulse from the crank angle sensor. There is no detection pulse from the output shaft speed sensor. There is no detection pulse from the vehicle speed sensor. The fail-safe function is not operational.

Scheme 37

Scheme 37: ROAD TEST

Scheme 38

Scheme 38

Scheme 39

Scheme 39: DIAGNOSTIC TROUBLE CODE DESCRIPTION

Scheme 40

Scheme 40

HYDRAULIC PRESSURE TEST

  1. Warm up the engine until the automatic transaxle fluid temperature is 80-100°C.
  2. Jack up the vehicle so that the wheels are free to turn.
  3. Connect the special tools oil pressure gauge to each pressure discharge port.
  4. Measure the hydraulic pressure at each port under the conditions given in the standard hydraulic pressure table, and check that the measured values are within the standard value ranges.
  5. If a value is outside the standard range, correct the problem while referring to «HYDRAULIC PRESSURE TEST DIAGNOSIS TABLE»(ref-172511-S29998402172005022800000) .

Scheme 41

Scheme 41

Scheme 42

Scheme 42

Scheme 43

Scheme 43

Scheme 44

Scheme 44: STANDARD HYDRAULIC PRESSURE TEST

Scheme 45

Scheme 45: OIL SEAL LOCATION

Scheme 46

Scheme 46: HYDRAULIC PRESSURE TEST DIAGNOSIS TABLE

Scheme 47

Scheme 47

Scheme 48

Scheme 48: DTC P1702-P1704: Throttle Position Sensor System

Scheme 49

Scheme 49

Scheme 50

Scheme 50: DTC P0712 & P0713: Oil Temperature Sensor System

Scheme 51

Scheme 51

Scheme 52

Scheme 52: DTC P0725: Crankshaft Position Sensor System

Scheme 53

Scheme 53

Scheme 54

Scheme 54: DTC P0715: Input Shaft Speed Sensor System

Scheme 55

Scheme 55

Scheme 56

Scheme 56: DTC P0720: Output Shaft Sensor System

Scheme 57

Scheme 57

Scheme 58

Scheme 58: DTC P0703: Stop Light Switch System

Scheme 59

Scheme 59

Scheme 60

Scheme 60: DTC P0750, P0755, P0760 & P0765: Solenoid Valve Systems

Scheme 61

Scheme 61

Scheme 62

Scheme 62: DTC P0740 & P0743: Torque Converter Clutch Solenoid System

Scheme 63

Scheme 63: DTC P0731: 1st Gear Incorrect Ratio

Scheme 64

Scheme 64

Scheme 65

Scheme 65: DTC P0732: 2nd Gear Incorrect Ratio

Scheme 66

Scheme 66

Scheme 67

Scheme 67: DTC P0733: 3rd Gear Incorrect Ratio

Scheme 68

Scheme 68

Scheme 69

Scheme 69: DTC P0734: 4th Gear Incorrect Ratio

Scheme 70

Scheme 70

Scheme 71

Scheme 71: DTC P0736: Reverse Gear Incorrect Ratio

Scheme 72

Scheme 72

Scheme 73

Scheme 73: DTC P1723: A/T Control Relay System

Scheme 74

Scheme 74

Scheme 75

Scheme 75: INSPECTION PROCEDURE 1

Scheme 76

Scheme 76

Scheme 77

Scheme 77: INSPECTION PROCEDURE 2

Scheme 78

Scheme 78

Scheme 79

Scheme 79: INSPECTION PROCEDURE 3

Scheme 80

Scheme 80

Scheme 81

Scheme 81: INSPECTION PROCEDURE 4

Scheme 82

Scheme 82

Scheme 83

Scheme 83: INSPECTION PROCEDURE 5

Scheme 84

Scheme 84

Scheme 85

Scheme 85: INSPECTION PROCEDURE 6

Scheme 86

Scheme 86

Scheme 87

Scheme 87: INSPECTION PROCEDURE 7

Scheme 88

Scheme 88

Scheme 89

Scheme 89: INSPECTION PROCEDURE 8

Scheme 90

Scheme 90

Scheme 91

Scheme 91: INSPECTION PROCEDURE 9

Scheme 92

Scheme 92

Scheme 93

Scheme 93: INSPECTION PROCEDURE 10

Scheme 94

Scheme 94

Scheme 95

Scheme 95: INSPECTION PROCEDURE 11

Scheme 96

Scheme 96

Scheme 97

Scheme 97: INSPECTION PROCEDURE 12

Scheme 98

Scheme 98

Scheme 99

Scheme 99: INSPECTION PROCEDURE 13

Scheme 100

Scheme 100

Scheme 101

Scheme 101: INSPECTION PROCEDURE 14

Scheme 102

Scheme 102

Scheme 103

Scheme 103: INSPECTION PROCEDURE 15

Scheme 104

Scheme 104
