Wheel Alignment Specifications & Adjustment Procedures: Specifications — Hyundai Sonata IV рестайлинг (2001-2012)

Wheel Alignment Specifications & Adjustment Procedures: Specifications Hyundai Sonata IV рестайлинг

Front Suspension Specification

Model	Free Height mm (in.)	Identification Color
2.4/2.7 GL + S/R 2.4/2.7 GL + A/C 2.4/2.7 GL + A/T (+S/R) 2.4 GLS	383.4 (15.1)	White - Green
2.4/2.7 GL + A/C + S/R 2.4/2.7 GL + A/T + A/C (+S/R) 2.7 GLS 2.4/2.7 GLS + S/R 2.4/2.7 GLS + A/T (+S/R)	389.6 (15.3)	Red - White
GL, GLS: Trim Level M/T: Manual Transaxle A/T: Automatic Transaxle A/C: Air Conditioning S/R: Sun Roof

COIL SPRING FREE HEIGHT & IDENTIFICATION COLOR

Type (Identification Color)		Gas (Yellow), Oil (Green)
Stroke		125.5 mm (4.94 in.)
Damping Force at 0.3 m/s
Expansion		1160 +/- 170 N (116 +/- 17 kg)
Compression		680 +/- 130 N (68 +/- 13 kg)

SHOCK ABSORBER

Rear Suspension Specification

Model	Free Height mm (in.)	Identification Color
All	354 (13.94)	Green - Red

COIL SPRING FREE HEIGHT & IDENTIFICATION COLOR

Type		Gas Pressurized Type
Stroke		177.5 mm (7 in.)
Damping Force at 0.3 m/s
Expansion		600 +/- 100 N (62 +/- 10 kg)
Compression		300 +/- 70 N (30 +/- 7 kg)

SHOCK ABSORBER

Wheel & Tire Specification

Wheel and Tire
Wheel type	Steel	Aluminum
Wheel size	6.0J x 15	6.0J x 15, 6.0J x 16
Tire size		P205/65/R15, P205/60/R16
Tire inflation pressure		207 kPa (30 psi)
Temporary tire
Wheel size		4T x 15
Tire size		T125/80 R15
Tire inflation pressure kPa (psi)		414 kPa (60 psi)

Wheel & Tire Specification

Scheme 1

Scheme 1: SERVICE STANDARD

TIGHTENING TORQUE

Items	Nm	Kgf.cm
Wheel nut	90 ~ 110	900 ~ 1100
Drive shaft nut	200 ~ 280	2000 ~ 2800
Front upper arm ball joint self-locking nut	35 ~ 45	350 ~ 450
Front upper arm shaft nut	55 ~ 65	550 ~ 650
Front upper arm mounting nut	80 ~ 100	800 ~ 1000
Lower arm ball joint self-locking nut	75 ~ 90	750 ~ 900
Lower arm ball joint to knuckle mounting bolt	100 ~ 120	1000 ~ 1200
Lower arm to connector nut	100 ~ 120	1000 ~ 1200
Lower arm bushing (A) to sub-frame mounting bolt	100 ~ 120	1000 ~ 1200
Lower arm bushing (G) to sub-frame mounting bolt	120 ~ 140	1200 ~ 1400
Fork lower mounting nut	100 ~ 120	1000 ~ 1200
Strut lower mounting bolt	60 ~ 80	600 ~ 800
Strut upper mounting nut	45 ~ 60	450 ~ 600
Strut mounting self-locking nut	20 ~ 25	200 ~ 250
Stabilizer link mounting self-locking nut	35 ~ 45	350 ~ 450
Stabilizer bar bracket to sub-frame bolt	30 ~ 45	300 ~ 450
Stabilizer bar bracket to crossmember bolt	35 ~ 45	350 ~ 450
Center arm to carrier nut	60 ~ 72	600 ~ 720
Rear shock absorber lower mounting bolt *	80 ~ 90	800 ~ 900
Rear shock absorber mounting self-locking nut	20 ~ 25	200 ~ 250
Rear upper arm to rear carrier mounting nut	100 ~ 120	1000 ~ 1200
Rear shock absorber mounting stud	100 ~ 120	1000 ~ 1200
Rear shock absorber mounting bracket to body mounting bolt	100 ~ 120	1000 ~ 1200
Rear upper arm to rear shock absorber mounting bracket	60 ~ 78	600 ~ 780
Assist arm to carrier *	100 ~ 120	1000 ~ 1200
Assist arm to crossmember nut *	80 ~ 100	800 ~ 1000
Center arm to carrier nut	60 ~ 72	600 ~ 720
Center arm to crossmember nut	100 ~ 120	1000 ~ 1200
Trailing arm to body nut *	140 ~ 160	1400 ~ 1600
Trailing arm to carrier nut *	100 ~ 120	1000 ~ 1200
Crossmember to body mounting bolt	100 ~ 120	1000 ~ 1200
Tie rod end lock nut	50 ~ 55	500 ~ 550

Torque Specifications

CAUTION

Replace the self-locking nuts with new ones after removal. The mark '*' indicates the parts which should be temporarily tightened, and then fully tightened with the vehicle on the ground in an unladen condition.
