Front Suspension System: Specifications Hyundai Sonata IV рестайлинг

Suspension Front 13 illustrations ~178 words

Front Suspension Specification

ModelFree Height mm (in.)Identification Color
2.4/2.7 GL + S/R 2.4/2.7 GL + A/C 2.4/2.7 GL + A/T (+S/R) 2.4 GLS383.4 (15.1)White - Green
2.4/2.7 GL + A/C + S/R 2.4/2.7 GL + A/T + A/C (+S/R) 2.7 GLS 2.4/2.7 GLS + S/R 2.4/2.7 GLS + A/T (+S/R)389.6 (15.3)Red - White
GL, GLS: Trim Level M/T: Manual Transaxle A/T: Automatic Transaxle A/C: Air Conditioning S/R: Sun Roof

COIL SPRING FREE HEIGHT & IDENTIFICATION COLOR

Type (Identification Color)Gas (Yellow), Oil (Green)
Stroke125.5 mm (4.94 in.)
Damping Force at 0.3 m/s
Expansion1160 +/- 170 N (116 +/- 17 kg)
Compression680 +/- 130 N (68 +/- 13 kg)

SHOCK ABSORBER

Scheme 1

Scheme 1: SERVICE STANDARD

TIGHTENING TORQUE

ItemsNmKgf.cm
Wheel nut90 ~ 110900 ~ 1100
Drive shaft nut200 ~ 2802000 ~ 2800
Front upper arm ball joint self-locking nut35 ~ 45350 ~ 450
Front upper arm shaft nut55 ~ 65550 ~ 650
Front upper arm mounting nut80 ~ 100800 ~ 1000
Lower arm ball joint self-locking nut75 ~ 90750 ~ 900
Lower arm ball joint to knuckle mounting bolt100 ~ 1201000 ~ 1200
Lower arm to connector nut100 ~ 1201000 ~ 1200
Lower arm bushing (A) to sub-frame mounting bolt100 ~ 1201000 ~ 1200
Lower arm bushing (G) to sub-frame mounting bolt120 ~ 1401200 ~ 1400
Fork lower mounting nut100 ~ 1201000 ~ 1200
Strut lower mounting bolt60 ~ 80600 ~ 800
Strut upper mounting nut45 ~ 60450 ~ 600
Strut mounting self-locking nut20 ~ 25200 ~ 250
Stabilizer link mounting self-locking nut35 ~ 45350 ~ 450
Stabilizer bar bracket to sub-frame bolt30 ~ 45300 ~ 450
Stabilizer bar bracket to crossmember bolt35 ~ 45350 ~ 450
Center arm to carrier nut60 ~ 72600 ~ 720
Rear shock absorber lower mounting bolt *80 ~ 90800 ~ 900
Rear shock absorber mounting self-locking nut20 ~ 25200 ~ 250
Rear upper arm to rear carrier mounting nut100 ~ 1201000 ~ 1200
Rear shock absorber mounting stud100 ~ 1201000 ~ 1200
Rear shock absorber mounting bracket to body mounting bolt100 ~ 1201000 ~ 1200
Rear upper arm to rear shock absorber mounting bracket60 ~ 78600 ~ 780
Assist arm to carrier *100 ~ 1201000 ~ 1200
Assist arm to crossmember nut *80 ~ 100800 ~ 1000
Center arm to carrier nut60 ~ 72600 ~ 720
Center arm to crossmember nut100 ~ 1201000 ~ 1200
Trailing arm to body nut *140 ~ 1601400 ~ 1600
Trailing arm to carrier nut *100 ~ 1201000 ~ 1200
Crossmember to body mounting bolt100 ~ 1201000 ~ 1200
Tie rod end lock nut50 ~ 55500 ~ 550

Torque Specifications

CAUTIONReplace the self-locking nuts with new ones after removal. The mark ' * ' indicates the parts which should be temporarily tightened, and then fully tightened with the vehicle on the ground in an unladen condition.

Scheme 2

Scheme 2: LUBRICANTS

Scheme 3

Scheme 3: SPECIAL TOOLS

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6: TROUBLESHOOTING

Scheme 7

Scheme 7

Scheme 8

Scheme 8: COMPONENTS

Scheme 9

Scheme 9: REMOVAL

Scheme 10

Scheme 10

Scheme 11

Scheme 11

Scheme 12

Scheme 12
  1. Remove the front wheel.
  2. Detach the brake hose from the front shock absorber mounting fork.
  3. Remove the fork lower mounting bolt from the front lower arm bush.
  4. Remove the strut lower mounting bolt then remove the fork from the strut assembly.
  5. Remove the strut upper mounting nuts (3), the front cap and top mounting ring.
  6. While pushing the axle assembly upward remove the strut assembly.

Scheme 13

Scheme 13: DISASSEMBLY
  1. Using the special tools (J38402, A-20) called spring compressor, compress the coil spring. NOTE: Do not use an impact wrench. It will damage the special tools.
  2. Remove the strut mounting self-locking nut, the washer and the front upper bushing (A) at the top end of the shock absorber.
  3. Remove the special tools (J38402, A-20), the front bracket assembly, the front spring upper pad and the front spring.
