Generators & Regulators (2.7L): Other Hyundai Sonata IV рестайлинг

Possible Causes

1. Fuse blown.
2. Light burned out.
3. Wiring connections loose.
4. Electronic voltage regulator faulty.

Possible Corrections

1. Check fuses.
2. Replace light.
3. Tighten loose connections.
4. Replace voltage regulator.

1. Generator drive belt loose or worn.
2. Battery cables loose, corroded or worn.
3. Fuse blown.
4. Fusible link blown.
5. Electronic voltage regulator or generator faulty.
6. Wiring fault.

1. Adjust tension or replace generator drive belt.
2. Repair or replace cables.
3. Check fuses.
4. Replace fusible link.
5. Test generator.
6. Repair wiring.

1. Generator drive belt loose or worn.
2. Wiring connections loose or open circuit.
3. Fusible link blown.
4. Warning indicator and pre-excitation resistor faulty.
5. Poor ground.
6. Electronic voltage regulator or generator faulty.
7. Battery.

1. Adjust tension or replace generator drive belt.
2. Tighten loose connections or repair wiring.
3. Replace fusible link.
4. Replace light, resistor or related components as necessary.
5. Repair ground.
6. Test generator.
7. Replace battery.

1. Electronic voltage regulator faulty.
2. Voltage sensing wire faulty.

1. Replace voltage regulator.
2. Repair wiring.

BRUSHES

1. Replace brushes if worn to limit. (Scheme 46) Replace all brush springs if any springs are damaged or corroded.
2. To remove brushes from holder, unsolder pigtail from terminal. (Scheme 47) To replace, install brush into the brush holder and solder lead wire.

Scheme 46

Scheme 47

ROTOR

1. Check Rotor Coil For Continuity - Check to make sure that there is continuity between the slip rings. (Scheme 48) Resistance should be 3.1 ohms. If resistance is extremely low, there is a short. If there is no continuity or if there is a short, replace generator. See «GENERATOR»(ref-168064-S00638544742004102900000) under REMOVAL & INSTALLATION.
2. Check Rotor Coil For Ground - Check to make sure that there is no continuity between the slip rings and the rotor shaft. (Scheme 49) If there is continuity, replace generator. See «GENERATOR»(ref-168064-S00638544742004102900000) under REMOVAL & INSTALLATION.

Scheme 48

Scheme 49

STATOR

Check Stator Coil For Grounding - Check to make sure that there is no continuity between the coil and generator housing. (Scheme 50) If there is continuity, replace the generator.

Scheme 50

Information not available from manufacturer. For removal and installation (Scheme 51)

Scheme 51
