Automatic Transaxle System: Overview Hyundai Sonata IV рестайлинг

Automatic Trans 24 illustrations ~257 words

Scheme 2

Scheme 2: SPECIFICATIONS (A/T)
Scheme 2: SPECIFICATIONS (A/T)

Scheme 3

Scheme 3: SERVICE SPECIFICATION (A/T)
Scheme 3: SERVICE SPECIFICATION (A/T)

Scheme 4

Scheme 4: LUBRICATIONS (A/T)
Scheme 4: LUBRICATIONS (A/T)

Scheme 5

Scheme 5: SEALANTS (A/T)
Scheme 5: SEALANTS (A/T)

Scheme 6

Scheme 6: SNAP RING FOR ADJUSTMENT & SPACER (A/T)
Scheme 6: SNAP RING FOR ADJUSTMENT & SPACER (A/T)

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9: SPECIAL TOOLS
Scheme 9: SPECIAL TOOLS

DIAGNOSTIC TROUBLE CODE IDENTIFICATION

DTCDefinition
P0703Stop Light Switch System
P0712Oil Temperature Sensor System
P0713Oil Temperature Sensor System
P0715Input Shaft Speed Sensor System
P0720Output Shaft Sensor System
P0725Crankshaft Position Sensor System
P07311st Gear Incorrect Ratio
P07322nd Gear Incorrect Ratio
P07333rd Gear Incorrect Ratio
P07344th Gear Incorrect Ratio
P0736Reverse Gear Incorrect Ratio
P0740Torque Converter Clutch Solenoid System
P0743Torque Converter Clutch Solenoid System
P0750Solenoid Valve Systems
P0755Solenoid Valve Systems
P0760Solenoid Valve Systems
P0765Solenoid Valve Systems
P1702Throttle Position Sensor System
P1703Throttle Position Sensor System
P1704Throttle Position Sensor System
P1723A/T Control Relay System

DIAGNOSTIC TROUBLE CODE (DTC) IDENTIFICATION

Scheme 10

Scheme 10: INSPECTION CHART FOR DIAGNOSIS CODES
Scheme 10: INSPECTION CHART FOR DIAGNOSIS CODES

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14: INSPECTION CHART FOR TROUBLE SYMPTOMS
Scheme 14: INSPECTION CHART FOR TROUBLE SYMPTOMS

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17: ELEMENTS IN USE IN EACH GEAR
Scheme 17: ELEMENTS IN USE IN EACH GEAR

Scheme 18

Scheme 18: OPERATING ELEMENTS & THEIR FUNCTION
Scheme 18: OPERATING ELEMENTS & THEIR FUNCTION

DESCRIPTION

  1. The hydraulic control system consists of the following components: Oil pump: Generates the hydraulic pressure. Regulator: Maintains the hydraulic pressure at a constant level. Solenoid valves: Convert TCM signals to hydraulic pressure. Pressure control valve: Controls the hydraulic pressure acting on the clutches and brakes according to the hydraulic pressure from the solenoid valves. Individual valves: Direct line pressure to the various oil lines. These components are all housed in the valve body.
  2. Independent electronic control of the hydraulic pressure from the clutch and brake solenoid valves realizes smooth and highly responsive gear shifts.
  3. Oil filter is provided in one place. Also, the use of a newly developed automatic transaxle fluid (ATF) ensures a longer ATF service life.
  4. To prevent the escape of ATF from the valve body, clutches and brakes when the engine is not running, the valve drainage ports are connected to a single drainage port that is located at a high point on the casing, and a ball check valve is fitted at the end of the drainage line.
  5. In the event of an electronic control system fault, a switch valve and fail-safe valve arrangement enables operation in 3rd gear or reverse.

Scheme 19

Scheme 19: PARK & NEUTRAL
Scheme 19: PARK & NEUTRAL

Scheme 20

Scheme 20: FIRST
Scheme 20: FIRST

Scheme 21

Scheme 21: SECOND
Scheme 21: SECOND

Scheme 22

Scheme 22: THIRD
Scheme 22: THIRD

Scheme 23

Scheme 23: FOURTH
Scheme 23: FOURTH

Scheme 24

Scheme 24: REVERSE
Scheme 24: REVERSE

Scheme 25

Scheme 25: COMPONENTS
Scheme 25: COMPONENTS
