Computer data lines 2.4l — 2.4l, computer data lines Hyundai Sonata IV

Components on these wiring diagrams 23

Click a component to highlight it on every diagram it appears on.

• 12 3 Sens Grd Flash Source
• 15 14 Flash Source Flash Source
• 7 5 K-Line Spark Timing
• A/T
• ABS Control Module
• Check Connector
• Data Input/ Output
• Data Link Connector
• ECM Control Relay
• Electronic Power Steering Control Module
• Engine Compartment Junction Block
• Engine Control Module
• Engine/Transmission Control Module
• Fuse 20
• Junction Connector
• K Line
• Keyless Entry Control Module
• M/T
• Passenger Compartment Junction Block
• Spark Timing
• SRS Control Module
• Sunroof Fuse
• Vehicle Speed Sensor
