Engine Controls - Service & Adjustment Specifications: Other Hyundai Sonata IV

Specifications 4 illustrations ~159 words

ENGINE COMPRESSION

Check engine compression with engine at normal operating temperature, at specified cranking speed, all spark plugs removed and throttle wide open.

Application(1) Specification
Compression Ratio
Accent (1.5L)10.0:1
Elantra (2.0L)10.3:1
Sonata
2.4L10.0:1
2.5L10.0:1
Tiburon (2.0L)10.3:1
Compression Pressure
Accent (1.5L)220-234 psi (15-16 kg/cm 2 )
Elantra (2.0L)199-213 psi (14-15 kg/cm 2 )
Sonata
2.4L178 psi (12 kg/cm 2 )
2.5L149-170 psi (10-12 kg/cm 2 )
Tiburon (2.0L)199-213 psi (14-15 kg/cm 2 )
Maximum Variation Between Cylinders
All Models14 psi (1 kg/cm 2 )
(1) Checked with engine coolant temperature at 176-205°F (80-96°C) and engine speed at 250-400 RPM.
(1)Checked with engine coolant temperature at 176-205°F (80-96°C) and engine speed at 250-400 RPM.

COMPRESSION SPECIFICATIONS

VALVE CLEARANCE

Note. All models are equipped with hydraulic lash adjusters. No adjustments are required.

IGNITION COIL

ApplicationPrimarySecondary
Accent (1.5L)0.45-0.5510,300-13,900
Elantra (2.0L)0.45-0.5510,300-13,900
Sonata
2.4L(1) 0.7820,000
2.5L0.67-0.8111,305-15,295
Tiburon (2.0L)0.45-0.5510,300-13,900
(1) Value is approximate with coil energized. See IGNITION CHECKS in BASIC DIAGNOSTIC PROCEDURES article.
(1)Value is approximate with coil energized. See IGNITION CHECKS in BASIC DIAGNOSTIC PROCEDURES article.

IGNITION COIL RESISTANCE - Ohms @ 68°F (20°C)

HIGH-TENSION WIRE RESISTANCE

Wire Application(1) Ohms
Accent (1.5L)
No. 14,800
No. 210,000
No. 37300
No. 412,000
Elantra (2.0L)
No. 115,300
No. 212,400
No. 310,700
No. 48800
Sonata
2.4L(2)
2.5L
No. 14390-6590
No. 22280-3430
No. 33490-5240
No. 41900-2860
No. 53250-4870
No. 61300-1950
Tiburon (2.0L)
No. 115,300
No. 212,400
No. 310,700
No. 48800
(1) Resistance should not be more than 10,000 ohms per foot of spark plug cable. (2) Sonata 2.4L engine uses 2 ignition coils with an internal power transistor. Coil No. 1 is located on cylinder No. 4 spark plug. Coil No. 2 is located on cylinder No. 2 spark plug.
(1)Resistance should not be more than 10,000 ohms per foot of spark plug cable.
(2)Sonata 2.4L engine uses 2 ignition coils with an internal power transistor. Coil No. 1 is located on cylinder No. 4 spark plug. Coil No. 2 is located on cylinder No. 2 spark plug.

HIGH-TENSION WIRE RESISTANCE

SPARK PLUGS

ApplicationNumber
Accent (1.5L)
ChampionRC9YC4/RC10YC4
NGKBKR5ES-11
Elantra (2.0L)
ChampionRN9YC4/RC10YC4
NGKBKR5ES-11
Sonata
2.4L
ChampionRN10PYP4
NGKPGR5C-11
2.5L
ChampionRC10PYP4
NGKPFR5N-11/PFR6N-11
Tiburon (2.0L)
ChampionRN9YC4/RC10YC4
NGKBKR5ES-11

SPARK PLUG TYPE

ApplicationGap In. (mm)Torque Ft. Lbs. (N.m)
All Models0.039-0.043 (1.0-1.1)15-21 (20-28)

SPARK PLUG SPECIFICATIONS

FIRING ORDER & TIMING MARKS

Note. To determine firing order see appropriate illustration. (Scheme 1)- (Scheme 4).

Firing Order (Accent 1.5L). Scheme 1

Scheme 1: Firing Order (Accent 1.5L)
Scheme 1: Firing Order (Accent 1.5L)

Firing Order (Elantra & Tiburon 2.0L). Scheme 2

Scheme 2: Firing Order (Elantra & Tiburon 2.0L)
Scheme 2: Firing Order (Elantra & Tiburon 2.0L)

Firing Order (Sonata 2.4L). Scheme 3

Scheme 3: Firing Order (Sonata 2.4L)
Scheme 3: Firing Order (Sonata 2.4L)

Firing Order (Sonata 2.5L). Scheme 4

Scheme 4: Firing Order (Sonata 2.5L)
Scheme 4: Firing Order (Sonata 2.5L)

IGNITION TIMING

Application(1) Base Timing
Accent (1.5L)4-14° @ 700-900
Elantra (2.0L)5-15° @ 700-900
Sonata
2.4L3-7° @ 700-900
2.5L7-17° @ 600-800
Tiburon (2.0L)5-15° @ 700-900
(1) Ignition timing is not adjustable.
(1)Ignition timing is not adjustable.

IGNITION TIMING (Degrees BTDC @ RPM)

FUEL PUMP

ApplicationAt Idle W/ Vacuum psi (kg/cm2)At Idle W/O Vacuum psi (kg/cm2)
Accent (1.5L)36 (2.5)44 (3.0)
Elantra (2.0L)37 (2.6)44 (3.0)
Sonata (2.4L & 2.5L)39 (2.7)46-49 (3.2-3.4)
Tiburon (2.0L)37 (2.6)44 (3.0)

REGULATED FUEL PRESSURE

INJECTOR RESISTANCE

Application(1) Ohms
Accent, Elantra & Tiburon15.6-16.3
Sonata13.0-16.0
(1) Resistance measured at 68°F (20°C).
(1)Resistance measured at 68°F (20°C).

INJECTOR RESISTANCE

IDLE SPEED & MIXTURE

Note. Idle speed and mixture are computer-controlled.

FAST IDLE SPEED

Note. Fast idle speed is computer-controlled.

THROTTLE POSITION (TP) SENSOR

ApplicationOhms At IdleVolts At Idle
Accent, Elantra & Tiburon700-3400.100-.825
Sonata
2.4L3500-6500.300-.900
2.5L1600-2400.250-.800

TP SENSOR SPECIFICATIONS
