Removal & Installation
- Remove side view mirror inner cover. Remove side view mirror mounting screws, and remove mirror. Disconnect remote control connector (electric mirror).
- Remove screws from inside handle bezel and arm rest. Remove power window main switch and disconnect harness connector. Remove door panel retaining screws. Insert a flat screwdriver between trim fasteners and door panel, and pry it loose.
- Disconnect harness connectors at power window motor, door lock actuator, side view mirror and trunk lid opener switch. Remove door panel. Remove carrier plate bolts from regulator channel. Slide window to closed position and secure in place.
- Remove regulator retaining screws. Disconnect power window motor harness connector. Remove regulator and motor as an assembly. Remove screw attaching power window motor to window regulator. Separate power window motor from window regulator. To install, reverse removal procedure. (Scheme 1)
Scheme 1
Power Window System Wiring Diagram. Scheme 2
Scheme 2: Power Window System Wiring Diagram
