Removal & Installation - Automatic Transmission: Application Hyundai Sonata III рестайлинг

APPLICATION

TRANSAXLE APPLICATIONS

Note. For proper ATF type and checking procedures, see appropriate AUTOMATIC TRANSMISSION SERVICING article.

1. Remove drain plug and drain transaxle fluid. Remove air cleaner assembly. Remove battery. Disconnect fluid cooler hoses at top of transaxle and plug lines and fittings.
2. Remove control cable. Disconnect all electrical connectors from transaxle. Remove top transaxle-to-engine mounting bolts "C". (Scheme 192) Remove transaxle top mounting bracket.
3. Remove starter. Raise vehicle. Remove engine undercover panel. Remove both axle shaft assemblies, and intermediate shaft and bearing bracket assembly. See appropriate AXLE SHAFTS article in AXLE SHAFTS & TRANSFER CASES.
4. Support transaxle with appropriate jack. Remove transaxle lower brace, behind starter. Remove lower bellhousing cover to access torque converter bolts. Ensure transaxle is in Neutral. Remove torque converter bolts. Push torque converter into transaxle bellhousing, away from drive plate. Remove lower transaxle-to-engine mounting bolts. Remove transaxle from vehicle.

1. To install, reverse removal procedure. Before installing transaxle to engine, ensure torque converter is properly aligned with transaxle pump drive. Install transaxle-to-engine mounting bolts in correct locations. (Scheme 192) Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-2412-S13325093732000031800000).
2. Refill transaxle fluid to specified level on dipstick. Adjust control cable. Check neutral safety switch adjustment. See appropriate AUTOMATIC TRANSMISSION SERVICING article. Recheck fluid level with transaxle at normal operating temperature.

Scheme 192

1. Remove drain plug, and drain transaxle fluid into appropriate container. Remove air cleaner assembly. Disconnect fluid cooler hoses on top of transaxle, and plug all fittings and lines.
2. Remove control cable and speedometer cable. Disconnect all electrical connectors from transaxle. Remove starter. Remove top transaxle-to-engine mounting bolts "A". (Scheme 193)- (Scheme 195).
3. Support engine from top, or by floor jack from bottom. DO NOT damage engine oil pan. On Accent, Elantra and Tiburon, remove transaxle top mounting bracket. On Sonata, remove bolt hole rubber covers inside fenderwell, and remove transaxle mounting bracket bolts. Ensure transaxle is in Neutral.
4. Remove centermember support under engine. Remove lower bellhousing cover to access torque converter bolts. Index torque converter to drive plate and remove torque converter bolts. Push torque converter away from engine into transaxle. Reinstall centermember support under engine. DO NOT fully tighten bolts.
5. Remove undercover panel(s). Remove both axle shaft assemblies. See appropriate AXLE SHAFTS article in AXLE SHAFTS & TRANSFER CASES. Support transaxle with transmission jack. Remove lower transaxle-to-engine mounting bolts. Remove transaxle from vehicle.

1. To install, reverse removal procedure. Before installing transaxle to engine, ensure torque converter is properly aligned with transaxle pump drive.
2. Install transaxle-to-engine mounting bolts in correct locations. (Scheme 193)- (Scheme 195). Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-2412-S13325093732000031800000).
3. Refill transaxle fluid to correct level on dipstick. Adjust control cable. Check neutral safety switch adjustment. See appropriate AUTOMATIC TRANSMISSION SERVICING article. Recheck fluid level with transaxle at normal operating temperature.

Scheme 193

Scheme 194

Scheme 195
