Maintenance Information: Overview Hyundai Sonata III

Fuse & Circuit Breaker Identification

1. 1 - Not Used
2. 2 - 10 Amp Turn/Hazard Lights
3. 3 - 15 Amp Stoplights, Cruise Control, Turn Signal
4. 4 - 10 Amp Radio, Power Antenna, A/C Control Unit
5. 5 - 15 Amp Door Lock Control Unit, Relay & Actuator, Trunk Lid Opener, Fuel Filler Opener
6. 6 - 15 Amp Sun Roof
7. 7 - 20 Amp Rear Window Defroster
8. 8 - 10 Amp Trunk Compartment Light, Map Light, Personal & Vanity Lights, Digital Clock, Seat Belt Chime
9. 9 - Not Used
10. 10 - Not Used
11. 11 - 10 Amp Back-Up Light, Turn Signals, Alternator Relay, Hazard Switch, Inhibitor Switch
12. 12 - 10 Amp Digital Clock, Cluster, Cruise Control, TCU, Inhibit Switch, Seat Belt Timer, A/T & Ignition Key Lock Control
13. 13 - 10 Amp Sun Roof Relay, Power Window Relay, Headlight Relay, Condenser Fan High Speed Relay, Blend Door, High Speed Blower Relay, A/C Control Unit
14. 14 - 15 Amp (1989-90) Headlight Washer Not Used (1991)
15. 15 - 10 Amp Automatic transaxle
16. 16 - 15 Amp Wiper/Washer
17. 17 - 10 Amp Radio, Power Mirror
18. 18 - 15 Amp Cigarette Lighter
19. 19 - 15 Amp Horn
20. 20 - 10 Amp Air Conditioner Switch, Blower Motor, Blower Relay

Scheme 1

1. 1 - 30 Amp Amplifier
2. 2 - 10 Amp Turn/Hazard Lamps
3. 3 - 15 Amp Stoplights, Cruise Control, Interlock System
4. 4 - 10 Amp Radio, Power Antenna, ETACS
5. 5 - 15 Amp Door Lock Control Unit, Relay & Actuator, Trunk Lid Opener, Fuel Filler Opener
6. 6 - 15 Amp Sun Roof
7. 7 - 20 Amp Rear Window Defroster
8. 8 - 10 Amp Trunk Compartment Light, Map Light, Personal & Vanity Lights, Digital Clock, Seat Belts, Ret. Solenoid, Chime, Piezo Alarm
9. 9 - 15 Amp Passive Seat Belt Motor
10. 10 - 15 Amp Passive Seat Belt Motor
11. 11 - 10 Amp Back-Up Light, Turn/Hazard Lamps, Passive Restraint, Alternator Relay, Inhibitor Switch, ETACS
12. 12 - 10 Amp Digital Clock, Cluster, Cruise Control, TCU, Security System Interlock System
13. 13 - 10 Amp Sun Roof Relay, Power Window Relay, Headlight Relay, Condenser Fan High Speed Relay, Blend Door, High Speed Blower Relay, A/C Control Unit
14. 14 - Not Used
15. 15 - 10 Amp Automatic Transaxle, Cruise Control
16. 16 - 15 Amp Wiper/Washer Relay, ETACS Unit
17. 17 - 10 Amp Radio, Power Mirrors, Interlock System
18. 18 - 15 Amp Cigarette Lighter
19. 19 - 15 Amp Horn, Ignition Lock Solenoid, A/T & Ignition Key Lock Solenoid
20. 20 - 10 Amp Air Conditioner Switch, Blower Motor, Blower Relay

Scheme 2

1. A - Not Used
2. B - Not Used (1989) 20 Amp (Blue) (1990-91) Condensor Fan
3. C - 60 Amp (Yellow) Alternator

Sub-Fusible Link and Fuse Identification

1. A - 30 Amp (Pink) Power Windows
2. B - 30 Amp (Pink) Headlamps, Tail Lamps
3. C - 40 Amp (1989) (Green) 50 Amp (1990-91) (Green) Battery Power to Fuse Box
4. D - 20 Amp (Blue) ECI
5. E - 40 Amp (1989) (Green) 50 Amp (1990-91) (Green) Cooling Fan, A/C Compressor Controls
6. F - 30 Amp (Pink) Ignition Switch
7. 1 - 30 Amp Blower Control
8. 2 - Not Used
9. 3 - 20 Amp Headlamps
10. 4 - 10 Amp A/C Compressor Control
11. 5 - 10 Amp Headlamp Indicator
12. 6 - Not Used
13. 7 - 10 Amp Tail Lamps, Illumnation

Scheme 3

1. 1 - 30 Amp Amplifier
2. 2 - 10 Amp Turn/Hazard Lamps
3. 3 - 15 Amp Stoplights, Cruise Control
4. 4 - 10 Amp Radio, Power Antenna, A/C Control Unit, ETACS
5. 5 - 15 Amp Door Lock Control Unit, Relay & Actuator, Trunk Lid Opener, Fuel Filler Opener
6. 6 - 15 Amp Sun Roof
7. 7 - 20 Amp Rear Window Defroster
8. 8 - 10 Amp Trunk Compartment Light, Map Light, Personal & Vanity Lights, Digital Clock, Seat Belts, Ret. Solenoid, Chime, Piezo Alarm
9. 9 - Not Used
10. 10 - Not Used
11. 11 - 10 Amp Back-Up Light, Turn/Hazard Lamps, Alternator Relay, Inhibitor Switch, ETACS
12. 12 - 10 Amp Digital Clock, Cluster, Cruise Control, TCU
13. 13 - 10 Amp Sun Roof Relay, Power Window Relay, Headlight Relay, Condenser Fan High Speed Relay, Blend Door, High Speed Blower Relay, A/C Control Unit
14. 14 - Not Used
15. 15 - 10 Amp TCU, Inhibitor Switch, Overdrive Switch, E.C.T. Switch
16. 16 - 15 Amp Wiper/Washer Relay, Headlight Relay, E.T.A.C.S. Unit
17. 17 - 10 Amp Radio, Outside Mirror, A/T & Ignition Lock Control Unit
18. 18 - 15 Amp Cigarette Lighter, Tail Light Relay
19. 19 - 15 Amp Horn, Ignition Lock Solenoid, A/T & Ignition Key Lock Solenoid
20. 20 - 10 Amp Air Conditioner Switch, Blower Motor, Blower Relay

Scheme 4

1. 1 - 30 Amp Amplifier
2. 2 - 10 Amp Turn/Hazard Lamps
3. 3 - 15 Amp Stoplights, Cruise Control
4. 4 - 10 Amp Radio, Power Antenna, A/C Control Unit, ETACS
5. 5 - 15 Amp Door Lock Control Unit, Relay & Actuator, Trunk Lid Opener, Fuel Filler Opener
6. 6 - 15 Amp Sun Roof
7. 7 - 20 Amp Rear Window Defroster
8. 8 - 10 Amp Trunk Compartment Light, Map Light, Personal & Vanity Lights, Digital Clock, Seat Belts, Ret. Solenoid, Chime, Piezo Alarm
9. 9 - 15 Amp Passive Seat Belt Motor
10. 10 - 15 Amp Passive Seat Belt Motor
11. 11 - 10 Amp Back-Up Light, Turn/Hazard Lamps, Alternator Relay, Inhibitor Switch, ETACS
12. 12 - 10 Amp Digital Clock, Cluster, Cruise Control, TCU
13. 13 - 10 Amp Sun Roof Relay, Power Window Relay, Headlight Relay, Condenser Fan High Speed Relay, Blend Door, High Speed Blower Relay, A/C Control Unit
14. 14 - Not Used
15. 15 - 10 Amp TCU, Inhibitor Switch, Overdrive Switch, E.C.T. Switch
16. 16 - 15 Amp Wiper/Washer Relay, Headlight Relay, E.T.A.C.S. Unit
17. 17 - 10 Amp Radio, Outside Mirror, A/T & Ignition Lock Control Unit
18. 18 - 15 Amp Cigarette Lighter, Taillight Relay
19. 19 - 15 Amp Horn, Ignition Lock Solenoid, A/T & Ignition Key Lock Solenoid
20. 20 - 10 Amp Air Conditioner Switch, Blower Motor, Blower Relay

Scheme 5

Main Fusible Link Identification

1. A - Not Used
2. B - 20 Amp (Blue) Condensor Fan
3. C - 60 Amp (Yellow) Alternator

1. D - 30 Amp (Pink) Power Windows
2. E - 30 Amp (Pink) Headlamps, Tail Lamps
3. F - 50 Amp (Green) Battery Power to Fuse Box
4. E - 20 Amp (Blue) ECU
5. G - 30 Amp (Pink) Cooling Fan
6. H - 30 Amp (Pink) Battery Power to Ignition Switch
7. I - 50 Amp (Green) ABS Control Unit
8. 1 - 30 Amp Blower Control
9. 2 - Not Used
10. 3 - 20 Amp Headlamps
11. 4 - 10 Amp A/C Compressor Control
12. 5 - 10 Amp Headlamp Indicator
13. 6 - 10 Amp LH Tail Lamps
14. 7 - 10 Amp RH Tail Lamps, Illumnation

FUSE PANEL IDENTIFICATION - 1995-96

Fuse panel identification is not available from manufacturer.
