Suspension System - General Information Hyundai Santa Fe III

Suspension Front 6 illustrations ~330 words

Front Suspension

ItemSpecification
Suspension typeMacpherson Strut
Shock absorberTypeHPD (High Performance Damper)
Stabilizer Bar
Coil springFree Height [I.D. color]337.9 mm(13.3031 in.), [Gray/Yellow]

Rear Suspension

ItemSpecification
Suspension typeMulti link
Shock absorberTypeHPD (High Performance Damper)
Coil springFree Height [I.D. color]2WD270.8 mm(10.6614 in.), [Green/Green]
273.6 mm(10.7717 in.), [Red/Red]
4WD287.6 mm(11.3330 in.), [Pink/Pink]
291.2 mm(11.4646 in.), [Violet/Violet]

Wheel & Tire

ItemSpecification
FrontRear
Aluminum18 inch7.0J x 18
19 inch7.5J x 19
Tire18 inchFront235/60 R18
19 inchP235/55 R19
18 inchRear235/60 R18
19 inchP235/55 R19
Tire pressure kPa (psi)P235/55 R19230 (33)230 (33)
235/60 R18230 (33)230 (33)
T165/90 R17420(60)420(60)

Wheel Alignment

ItemSpecification
FrontRear
Toe-inIndividual0.05°±0.1°0.1°±0.1°
Total0.1°±0.2°0.2°±0.2°
Camber angle0.5°±0.5°1°±0.5°
Caster angle4.14°±0.5°
King-pin angle13.63°±0.5°
Ride height440±10mm (17.3228±0.3937 in.)445±10mm (17.5197±0.3937 in.)

Tightening Torque

ItemTightening torque (kgf.m)
NmKgf.mLb-ft
Tire wheel lug nuts88.3 ~ 107.99.0 ~ 11.065.1 ~ 79.6
Strut assembly to knuckle156.9 ~ 176.516.0 ~ 18.0115.7 ~ 130.2
Strut assembly lock nut53.94 ~ 73.555.5 ~ 7.539.78 ~ 54.25
Lower arm to sub frame (Front)117.7 ~ 137.312.0 ~ 14.086.8 ~ 101.3
Lower arm to sub frame (Rear)156.9 ~ 176.516.0 ~ 18.0115.7 ~ 130.2
Lower arm to knuckle98.1 ~ 117.710.0 ~12.072.3 ~ 86.8
Stabilizer link to strut assembly98.1 ~ 117.710.0 ~12.072.3 ~ 86.8
Stabilizer bar to stabilizer link98.1 ~ 117.710.0 ~ 12.072.3 ~ 86.8
Stabilizer bar to sub frame49.0 ~ 63.75.0 ~ 6.536.2 ~ 47.0
Roll rod bolt & nut107.9 ~ 127.511.0 ~ 13.079.6 ~ 94.0
Tie rod end nut23.5 ~ 33.32.4 ~ 3.417.4 ~ 24.6
Universal joint to pinion of steering gear32.4 ~ 37.33.3 ~ 3.823.9 ~ 27.5
Steering gear box to sub frame88.3 ~ 107.99.0 ~ 11.065.1 ~ 79.6
Sub frame mounting bolts (A)44.1 ~ 58.84.5 ~ 6.032.5 ~ 43.4
Sub frame mounting bolts (B)98.1 ~ 117.710.0 ~12.072.3 ~ 86.8
Sub frame mounting bolts (C)44.1 ~ 58.84.5 ~ 6.032.5 ~ 43.4
Sub frame mounting bolts (D)156.9 ~ 176.516.0 ~ 18.0115.7 ~ 130.2

TIGHTENING TORQUE SPECIFICATION - FRONT SUSPENSION

ItemTightening torque (kgf.m)
NmKgf.m
Tire wheel lug nuts88.3 ~ 107.99.0 ~ 11.0
Trailing arm to body98.1 ~ 117.710.0 ~ 12.0
Trailing arm to knuckle44.1 ~ 53.94.5 ~ 5.5
Assist arm to sub frame137.3 ~ 156.914.0 ~ 16.0
Assist arm to knuckle2WD44.1 ~ 53.94.5 ~ 5.5
4WD137.3 ~ 156.914.0 ~ 16.0
Lower arm to knuckle137.3 ~ 156.914.0 ~ 16.0
Upper arm to sub frame2WD137.3 ~ 156.914.0 ~ 16.0
4WD98.0 ~ 117.710.0 ~ 12.0
Lower arm to sub frame137.3 ~ 156.914.0 ~ 16.0
Upper arm to knuckle2WD137.3 ~ 156.914.0 ~ 16.0
4WD98.1 ~ 117.710.0 ~ 12.0
Shock absorber cover to frame2WD88.3 ~ 107.99.0 ~ 11.0
Shock absorber to frame137.3 ~ 156.914.0 ~ 16.0
Shock absorber to knuckle137.3 ~ 156.914.0 ~ 16.0
Stabilizer bar to stabilizer link98.1 ~ 117.710.0 ~ 12.0
Stabilizer bar to sub frame44.1 ~ 53.94.5 ~ 5.5
Sub frame mounting bolt & nut176.5 ~ 215.718.0 ~ 22.0

TIGHTENING TORQUE SPECIFICATION - REAR SUSPENSION

Special Service Tools

Tool (Number and Name) Illustration Use 09546-26000 Strut spring compressor Compression of coil spring

Scheme 50

Scheme 50: Special Service Tools

Troubleshooting

SymptomPossible causeRemedy
Hard steeringImproper front wheel alignment Excessive turning resistance of lower arm ball joint Low tire pressure No power assistCorrect Replace Adjust Repair and replace
Poor return of steering wheel to centerImproper front wheel alignmentCorrect
Poor or rough rideImproper front wheel alignment Malfunctioning shock absorber Broken or worn stabilizer Broken or worn coil spring Worn lower arm bushingCorrect Repair or replace Replace Replace Replace the lower arm assembly
Abnormal tire wearImproper front wheel alignment Improper tire pressure Malfunctioning shock absorberCorrect Adjust Replace
WanderingImproper front wheel alignment Poor turning resistance of lower arm ball joint Loose or worn lower arm bushingCorrect Repair Retighten or replace
Vehicle pulls to one sideImproper front wheel alignment Excessive turning resistance of lower arm ball joint Broken or worn coil spring Bent lower armCorrect Replace Replace Repair
Steering wheel shimmyImproper front wheel alignment Poor turning resistance of lower arm ball joint Broken or worn stabilizer Worn lower arm bushing Malfunctioning shock absorber Broken or worn coil springCorrect Replace Replace Replace Replace Replace
BottomingBroken or worn coil spring Malfunctioning shock absorberReplace Replace

Wheel/tire noise, vibration and harshness concerns are directly related to vehicle speed and are not generally affected by acceleration, coasting or decelerating. Also, out-of-balance wheel and tires can vibrate at more than one speed. A vibration that is affected by the engine RPM, or is eliminated by placing the transmission in Neutral is not related to the tire and wheel. As a general rule, tire and wheel vibrations felt in the steering wheel are related to the front tire and wheel assemblies. Vibrations felt in the seat or floor are related to the rear tire and wheel assemblies. This can initially isolate a concern to the front or rear.

Careful attention must be paid to the tire and wheels. There are several symptoms that can be caused by damaged or worn tire and wheels. Perform a careful visual inspection of the tires and wheel assemblies. Spin the tires slowly and watch for signs of lateral or radial runout. Refer to the WHEEL AND TIRE DIAGNOSTIC chart to determine the tire wear conditions and actions

Wheel and tire diagnosis Rapid wear at the center Rapid wear at both shoulders Wear at one shoulder Center-tread down to fabric due to excessive over inflated tires Lack of rotation Excessive toe on drive wheels Heavy acceleration on drive Under-inflated tires Worn suspension components Excessive cornering speeds Lack of rotation Toe adjustment out of specification Camber out of specification Damaged strut Damaged lower arm Partial wear Feathered edge Wear pattern Caused by irregular burrs on brake drums Toe adjustment out of specification Damaged or worn tie rods Damaged knuckle Excessive toe on non-drive wheels Lack of rotation

Scheme 51

Scheme 51

Scheme 52

Scheme 52

Scheme 53

Scheme 53

Scheme 54

Scheme 54

Scheme 55
