Steering System - General Information Hyundai Santa Fe III

Oem General Information 2 illustrations ~169 words

Specifications

ItemSpecification
TypeMotor Driven Power Steering
Steering gearTypeRack & Pinion
Rack stroke160mm
Steering angle (Max.)Inner38.79°±1°30'
Outer31.92°

Tightening Torques

ItemTightening torque (kgf.m)
NmKgf.mLb-ft
Tire wheel lug nuts88.3 ~ 107.99.0 ~ 11.065.1 ~ 79.6
Steering wheel lock nut44.1 ~ 49.04.5 ~ 5.032.5 ~ 36.2
Steering column assembly to Universal joint49.0~58.85.0~6.036.2 ~43.4
Steering column mounting bolts44.1 ~ 49.04.5 ~ 5.032.5 ~ 36.2
Steering column mounting nuts12.7 ~ 17.71.3 ~ 1.89.4 ~ 13.0
Universal joint to pinion of steering gear32.4 ~ 37.33.3 ~ 3.823.9 ~ 27.5
Tie rod end castle nut23.5 ~ 33.32.4 ~ 3.417.4 ~ 24.6
Steering gear box to sub frame88.3 ~ 107.99.0 ~ 11.065.1 ~ 79.6
Stabilizer link nut98.1 ~ 117.710.0 ~ 12.072.3 ~ 86.8
Roll rod mounting bolt & nut107.9 ~ 127.511.0 ~13.079.6 ~ 94.0
Lower arm to knuckle98.1 ~ 117.710.0 ~12.072.3 ~ 86.8
Sub frame mounting bolts(A) 44.1 ~ 58.84.5 ~ 6.032.5 ~ 43.4
(B) 156.9 ~ 176.516.0 ~ 18.0115.7 ~ 130.2

STEERING SYSTEM TORQUE SPECIFICATIONS

Special Service Tools

Tool (Number and Name) Illustration Use 09561-11001 Steering wheel puller Remove the steering wheel

Scheme 1

Scheme 1: Steering Wheel Play Inspection
Scheme 1: Steering Wheel Play Inspection
  1. Turn the steering wheel so that the front wheels can face straight ahead.
  2. Measure the distance the steering wheel can be turned without moving the front wheels. Standard value : 30mm (1.1811in.) or less Information The engine must be running to perform this test.
  3. If the play exceeds standard value, inspect the steering column, shaft, and linkages.

Scheme 2

Scheme 2: Checking stationary steering effort
Scheme 2: Checking stationary steering effort
  1. Position the vehicle on a level surface and place the steering wheel in the straight ahead position.
  2. Attach a spring scale to the steering wheel. With the engine speed 900 ~ 1100 rpm, pull the scale and read it as soon as the tires begin to turn. Standard value : 3.0kgf or less Information The engine must be running to perform this test.
  3. If the measured value exceeds standard value, inspect the power steering gear box and MDPS system.
