Fuses and Relays Hyundai Santa Fe III

Fuses & Circuit Breakers 27 illustrations ~1259 words

Scheme 1

Scheme 1: Component Location
Scheme 1: Component Location

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3: Component Location
Scheme 3: Component Location

Circuit (E/R Fuse & Relay Box)

Fuse Name(A)Circuit Protected
MULTI FUSEMDPS80AMDPS Unit
B+260ASmart Junction Box (IPS 1 (4CH), IPS 2 (1CH), IPS 5 (1CH), Fuse - SUNROOF 1, P/SEAT PASS, P/SEAT DRV, BLOWER RR)
BLOWER40ABlower Relay
RR HTD40ARear Defogger Relay
ABS140AESC Module, Multipurpose Check Connector
ABS240AESC Module
C/FAN60ACooling Fan Relay
B+360ASmart Junction Box (Fuse - MODULE 1, SMART KEY 4, SUNROOF 2, SMART KEY 1, Leak Current Autocut Device)
FUSEB+450ASmart Junction Box (IPS 3 (4CH), IPS 6 (2CH), Fuse - F/LID, STOP LAMP, DR LOCK BRAKE SWITCH)
EMS40AEMS Box
IG140AW/O Smart Key: Ignition Switch, With Smart Key - ACC Relay, IG1 Relay
IG240AStart Relay, IG2 Relay, W/O Smart Key: Ignition Switch
PYTAIL GATE30APower Tail Gate Module
TRAILER30ATrailer Power Outlet
B+150ASmart Junction Box (Fuse - S/HEATER RR, S/HEATER FRT, P.WDW RH, P/WDW LH, AMP)
AC INVERTER30AAC Inverter Module
HORN15AHorn Relay
DEICER15AFront Deicer Relay
POWER OUTLET25APower Outlet Relay
4WD20A4WD ECM
AMS10ABattery Sensor
IDB15AIDB (Injector Driver Box)
AMS (WIPER)10ABCM, PCM
WIPER FRT25AWiper LO Relay, Front Wiper Motor
B/UP LAMP10ARear Combination Lamp (IN) LH/RH, Electro Chromic Mirror, Audio, A/V & Navigation Head Unit
ABS37.5AESC Module
SENSORS7.5APCM, IDB (Injector Driver Box)
TCU15ATransaxle Range Switch

* USE THE DESIGNATED FUSE AND RELAY ONLY

Scheme 4

Scheme 4
Scheme 4

Circuit (EMS Box)

Fuse Name(A)Circuit Protected
F/PUMP15AFuel Pump Relay
ECU 115APCM
ECU 210AIDB (Injector Driver Box)
SENSOR 310AFuel Pump Relay, PCM
IGN COIL20ACondenser #1/#2, Ignition Coil #1/#2/#3/#4/#5/#6
SENSOR 210APurge Control Solenoid Valve, Variable Intake Solenoid Valve #1/#2, Oil Control Valve #1/#2/#3/#4, Canister Close Valve, PCM
SENSOR 115AOxygen Sensor #1/#2/#3/#4, E/R Fuse & Relay Box (Cooling Fan Relay), PCM
SENSOR 420A
B/A HORN10ABurglar Alarm Horn Relay

* USE THE DESIGNATED FUSE AND RELAY ONLY

Inspection

  1. Disconnect the negative (-) battery terminal.
  2. Pull out the relay from the engine compartment relay box.

Power Relay (Type A)

Check for continuity between the terminals.

Scheme 5

Scheme 5: Power Relay (Type A)
Scheme 5: Power Relay (Type A)

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7
  1. Power outlet relay
  2. Start relay
  3. Front deicer relay
  4. Blower relay
  5. ACC relay
  6. IG1 relay
  7. IG2 relay
  8. Rear defogger relay
  9. Horn relay
  10. Vacuum pump relay There should be continuity between the No. 30 and No. 87 terminals when power and ground are connected to the No. 85 and No. 86 terminals. There should be no continuity between the No. 30 and No. 87 terminals when power is disconnected.

Power Relay (Type B)

Check for continuity between the terminals.

Scheme 8

Scheme 8: Power Relay (Type B)
Scheme 8: Power Relay (Type B)

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. Wiper relay (Low)
  2. Wiper relay (High) There should be continuity between the No. 30 and No. 87 terminals when power and ground are connected to the No. 85 and No. 86 terminals. There should be continuity between the No. 30 and No. 87 terminals when power is disconnected.

Power Relay (Type C)

Check for continuity between the terminals.

Scheme 11

Scheme 11: Power Relay (Type C)
Scheme 11: Power Relay (Type C)

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13
  1. Cooling fan relay There should be continuity between the No. 30 and No. 87 terminals when power and ground are connected to the No. 85 and No. 86 terminals. There should be no continuity between the No. 30 and No. 87 terminals when power is disconnected.

Scheme 14

Scheme 14: Replacement of EMS box
Scheme 14: Replacement of EMS box

Scheme 15

Scheme 15
Scheme 15
  1. Disconnect the negative (-) battery terminal.
  2. Push 4 hooks in the engine room relay box out to the arrow direction and put up the EMS box assembly (A).
  3. Disconnect the connector and remove the EMS box assembly (A).
  1. Be sure there is no play in the fuse holders, and that the fuses are held securely.
  2. Are the fuse capacities for each circuit correct?
  3. Are there any blown fuses? NOTE: If a fuse is to be replaced, be sure to use a new fuse of the same capacity. Always determine why the fuse blew first and completely eliminate the problem before installing a new fuse.

Scheme 16

Scheme 16: Multi Fuse
Scheme 16: Multi Fuse

Information

  1. Multi fuse has to replace in the mass when it damaged only one fuse.
  2. When replacing the multi fuse, refer to «COMPONENT LOCATION»(/hyundai/santa-fe/iii-2012-2016/remont/fuses-circuit-breakers/#fuses-and-relays) .
  3. Use the multi fuse capacities for each circuit correctly.

Scheme 17

Scheme 17: Component Location
Scheme 17: Component Location
Possible SourcesAction
Fuse Name(A)Circuit Protected
A/BAG IND10AInstrument Cluster
A/BAG15ASRS Control Module, A/C Control Module, Passenger Occupant Detection Sensor.
MODULE 57.5ASunroof, Smart Key Control Module, Rear Blower Switch, BCM, Rear Seat Warmer LH/RH, ICM Relay Box (Rear Blower Relay), Driver/Passenger CCS Control Module, AC Inverter Module, Driver/Passenger seat warmer Module, Electro Chromic Mirror
MODULE 17.5ASport Mode Switch, Key Solenoid, Console Switch LR/RH, Rear Blower Switch, Rear Power Window Switch LH/RH
MEMORY 210ATire Pressure Monitoring Module, Electro Chromic Mirror, Instrument Cluster, Auto Light & Photo Sensor, Driver/Passenger Door Module, BCM, Driver IMS Module, Data Link Connector, A/C Control Module
SMART KEY 27.5ASmart Key Control Module, Immobilizer Module
MODULE 310ABCM, Instrument Cluster, Tire Pressure Monitoring Module, A/C Control Module, Driver/Passenger Door Module, ATM Shift Lever Indicator, Rear Seat Warmer LH/RH, 4WD ECM, Driver/Passenger CCS Control Module, Driver/Passenger Seat Warmer Module, MTS Module, Rear Parking Assist Sensor LH/RH, A/V & Navigation Head Unit, Rear Parking Assist Sensor (Center) LH/RH, AMP, Driver IMS Module, Electro Chromic Mirror, Blind Spot Detection LH/RH
SMART KEY 410AStart/Stop Button Switch, Immobilizer Module
INTERIOR LAMP15ACargo Lamp, Vanity Lamp LH/RH, Overhead Console Lamp, Center Room Lamp, Rear Personal Lamp LH/RH
MULTI MEDIA15AAudio, A/V & Navigation Head Unit, MTS Module
MDPS7.5AMDPS Unit
HTD STRG15ASteering Wheel Switch
MEMORY 110ARF Receiver, Ignition Key II & Door Warning Switch
START7.5AW/O IMMD, & Smart Key: ICM Relay Box (Burglar Alarm Relay), With IMMO, or Smart Key: Transaxle Range Switch
MODULE 210ACrash Pad Switch, Multipurpose Check Connector, Head Lamp Leveling Device Actuator LH/RH, Auto Head Lamp Leveling Device Module, Stop Lamp Switch
SUNROOF 220ASunroof
S/HEATER RR15ARear Seat Warner LH/RH
IGN20AE/R Fuse & Relay Box (Fuse - ABS3, SENSOR 5, TCU)
A/CON 17.5AE/R Fuse & Relay Box (Blower Relay) A/C Control Module, Cluster Ionizer
WIPER RR15ARear Wiper Relay, Rear Wiper Motor, Multifunction Switch
SMART KEY 125ASmart Key Control Module
S/HEATER FRT20ADriver/Passenger CCS Control Module, Driver/Passenger Seat Warner Module
A/CON 27.5AA/C Control Module
C/LIGHTER20AFront Power Outlet & Cigarette Lighter, Luggage Power Outlet
WIPER FRT15AMultifunction Switch, E/R Fuse & Relay Box (Wiper HI Relay, K32 Relay)
BLOWER RR20AICM Relay Box (Rear Blower Relay)
P/WDW RH25APassenger Door Module, Rear Power Window Switch RH
RR HTD10AA/C Control Module
BRAKE SWITCH7.5ASmart Key Control Module, Stop Lamp Switch
SUNROOF 120ASunroof
P/WDW LH25ADriver Safety Power Window Module, Driver Door Module, Rear Power Window Switch LH
F/LID15AFuel Filter Door Switch
SMART KEY 37.5ASmart Key Control Module
STOP LAMP15AStop Signal Electronic Module
P/SEAT PASS20APassenger Seat Manual Switch
AMP30AAMP
MODULE 410AAudio, A/V & Navigation Head Unit, BCM, Overhead Console Lamp, AMP, MTS Module, Power Outside Mirror Switch, E/R Fuse & Relay Box (Power Outlet Relay)
DR LOCK20ADoor Lock/Unlock Relay, Tail Gate Relay, ICM Relay Box (Two Turn Unlock Relay)
P/SEAT DRY30ADriver Seat Manual Switch, Driver Lumber Supper Switch, Driver IMS Module

CIRCUIT SPECIFICATION (SMART JUNCTION BOX)

* USE THE DESIGNATED FUSE ONLY

Smart Junction Box (SJB)

  1. General function: Interior Junction Box + some functions of BCM It controls loads with CAN communication and IPS.
  2. Main function Low speed CAN communication (100 kbps) Self diagnostics (Lamp open/short) Fail safe (When MCU/CAN is fail, Head lamp/Tail lamp directly drive) Protection of bulb over-voltage (PWM function) Cut of Over-load and Short: PCL (Program Current Limit)

Scheme 18

Scheme 18: Auto Cut System Of Dark Current
Scheme 18: Auto Cut System Of Dark Current

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21
  1. Description: It cuts automatically power to be provided with load for reducing useless dark current according to vehicle state.
  2. SJB had 3 modes, "Normal Mode", "Sleep Mode", "Power Off Mode". Auto cut of dark current practice in "Sleep Mode". "Sleep" condition: IG OFF, constant input switch, CAN network doesn't activate. "Sleep" resolutive condition: Any switch inputs, CAN network activates, KEY ON, IGN ON "Power OFF" condition: The setting time of timer which is used by cutting a load power expires. "Normal Mode": SJB function normally activates. "Sleep Mode": It is low power mode and activates for reducing electricity consumption of SJB or IPM. Auto cut of dark current function activates. "Power OFF Mode": Power of MCU and circumferential circuit is cut for minimizing electricity consumption. Operation stops.
  3. The explanation - The auto cut of dark current Before delivering to customer Fuse switch OFF All door close & RKE door lock or Constant switch state (Auto cut of dark current scenario starts.) After "sleep" state is for 20 min. SJB power down (SJB dark current: 200 μA) and cutting power of Lamp/Body Load/Wake up After delivering to customer Fuse switch ON All door close & Constant switch state: C_BAState=OFF (Auto cut of dark current scenario starts.) After "sleep" state is for 20 min. SJB power down (SJB dark current: 200 μA) and cutting power of Lamp Load In case RKE door lock: C_BAState=ON & Trunk SW=CLOSE (Auto cut of dark current scenario starts.) After "Sleep" state 35s~65s (Waiting time of other unit: 30~60s + SJB sleep counts 5s) SJB Powerdown (SJB dark current: 200 μA) and cutting power of Lamp Load
  4. Problem when fuse switch setting is wrong : If a fuse switch is set to OFF (Before delivering to customer) by a customer or technician and auto cut function of dark current activates, below problems may happen. Symptom Related part Door lock/unlock, trunk open don't activate by RKE. (Wakeup of each module don't activate.) BCM Digital clock is reset. (Memory is reset.) Digital clock Setting value of audio (Volume, Frequency setting) is reset. (Memory is reset.) Audio * If fuse switch OFF (before delivering to customer) is set, power of BCM, Digital clock and audio is shut off.

Fuse Inspection

  1. Be sure there is no play in the fuse holders, and that the fuses are held securely.
  2. Are the fuse capacities for each circuit correct?
  3. Are there any blown fuses? NOTE: If a fuse is to be replaced, be sure to use a new fuse of the same capacity. Always determine why the fuse blew first and completely eliminate the problem before installing a new fuse.

Scheme 22

Scheme 22: Inspection
Scheme 22: Inspection

Scheme 23

Scheme 23
Scheme 23

Scheme 24

Scheme 24
Scheme 24
  1. The SJB can be diagnosed by using the GDS. The SJB communicates with the GDS which then displays inputs and outputs along with codes.
  2. To diagnose the SJB function, select the vehicle model, BCM and SJB.
  3. To consult the present input/out value of SJB, "Current DATA". It provides information of SJB input/output conditions.
  4. To perform functional test on SJB outputs, select "Actuation Test"

Scheme 25

Scheme 25: Passenger Compartment Junction Box (SJB)
Scheme 25: Passenger Compartment Junction Box (SJB)
  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad lower panel. Refer to «CRASH PAD LOWER PANEL»(/hyundai/santa-fe/iii-2012-2016/remont/gauges-instrument-panels/#crash-pad) .
  3. Disconnect the connectors from the fuse side of the smart junction box.
  4. Remove the smart junction box after loosening the mounting nuts (2EA) and bolt.
  5. Disconnect the connectors from the back side of the smart junction box.

Installation

  1. Install the smart junction box.
  2. Install the crash pad lower panel.
  3. Check that all system operates normally.

Scheme 26

Scheme 26: Component
Scheme 26: Component

Description

The ICM relay is united with (rear blower motor, rear fog lamp, two turn unlock, burglar alarm relay) which installed inside the lower crash pad.

Scheme 27

Scheme 27: Description
Scheme 27: Description

Rear Blower Motor relay

Check for continuity between the terminals.

  1. There should be continuity between the No. 16 and No. 15 terminals when power and ground are connected to the No. 13 and No. 14 in the ICM-A.

Rear Fog Lamp Relay

Check for continuity between the terminals.

  1. There should be continuity between the No. 11 and No. 10 terminals when power and ground are connected to the No. 11 and No. 14 in the ICM-B.

Two Turn Unlock Relay

Check for continuity between the terminals.

  1. There should be continuity between the No. 12 and No. 22 terminals when power and ground are connected to the No. 21 and No. 22 in the ICM-B.

Burglar Alarm Relay

Check for continuity between the terminals.

  1. There should be continuity between the No. 20 and No. 16 terminals when power and ground are connected to the No. 17 and No. 6 in the ICM-B.
