- Remove the front wheel and tire (A) from front hub. Tightening torque: 88.2 ~ 107.8 N.m (9.0 ~ 11.0 kgf.m, 65.0 ~ 79.5 lb-ft) NOTE: Be careful not to damage to the hub bolts when removing the front wheel and tire (A).
- Remove the coking nut (A). Tightening torque: 240.3~ 269.7 N.m (24.5 ~ 27.5 kgf.m, 177.2 ~ 198.9 lb-ft) NOTE: The front hub coking nut should be replaced with new ones. After installation coking nut (A), stake the coking nut using a chisel and hammer as shown in the illustration below.
- Remove the tie rod end ball joint (C) from the knuckle. Remove the split pin (A). Remove the castle nut (B). Tightening torque: 34.3 ~ 44.1 N.m (3.5 ~ 4.5 kgf.m, 25.3 ~ 32.5 lb-ft)
- Disconnect the ball joint (A) from knuckle using the special tool (09568-4A000).
- Remove the lower arm (A) mounting bolt and nut from the knuckle. Tightening torque: 98.0 ~ 117.6 N.m (10.0 ~ 12.0 kgf.m, 72.3 ~ 86.7 lb-ft)
- Using a plastic hammer (A), disconnect driveshaft (C) from the axle hub (B).
- Remove the RH side cover (A). Tightening torque: 7.8 ~ 11.8 N.m (0.8 ~ 1.2 kgf.m, 5.8 ~ 8.7 lb-ft)
- Loosen the inner shaft mounting bolts and then disconnect the inner shaft (A). Tightening torque: 49.0 ~ 68.6 N.m (5.0 ~ 7.0 kgf.m, 36.2 ~ 50.6 lb-ft) Information By the shape and the engine bracket bolts are mounted differently.
- Insert a pry bar (A) between the transaxle case and joint case, and separate the drive shaft (B) from the transaxle case.
- Install in the reverse order of removal. NOTE: Use a pry bar being careful not to damage the transaxle and joint. Do not insert the pry bar too deep, as this may cause damage to the oil seal. Do not pull the driveshaft by excessive force it may cause components inside the joint kit to dislodge resulting in a torn boot or a damaged bearing. Plug the hole of the transaxle case with the oil seal cap to prevent contamination. Support the driveshaft properly. Replace the retainer ring whenever the driveshaft is removed from the transaxle case.
- Check the front alignment. Refer to «FRONT ALIGNMENT»(/hyundai/santa-fe/iii-2012-2016/remont/suspension-front/#front-suspension-system-wheel-alignment) .
Scheme 18
Scheme 19
Removal
Note. Special grease must be applied to the driveshaft joint. Do not substitute with another type of grease. The boot band should be replaced with a new one.
Scheme 20
Scheme 21
Scheme 22
Scheme 23
Scheme 24
Scheme 25
Scheme 26
Scheme 27
- Remove the Front Driveshaft. Refer to «FRONT DRIVESHAFT»(/hyundai/santa-fe/iii-2012-2016/remont/driveshaft-universal-joints/#driveshaft-assembly) .
- Remove the housing circlip (B) from the driveshaft spline (A).
- Remove both boot bands from the TJ housing.
- Remove the TJ housing (A). Information Make alignment marks on spider roller assembly (A), joint case (B), and shaft spline (C) to aid reassembly.
- Remove the retainer ring (A) from the shaft.
- Remove the spider assembly (B) from the driveshaft (A) using the special tool (09495-33000).
- Clean the spider assembly.
- Remove the TJ boot (A). Information For reusing the boot (A), wrap tape (B) around the driveshaft splines (C) to protect the boot (A).
Inspection
- Check the spider assembly for roller rotation, wear or corrosion.
- Check the groove inside the joint case for wear or corrosion
- Check the TJ boots for damage and deterioration.
Scheme 28
Scheme 29
Scheme 30
- Wrap tape around the driveshaft spline (TJ) to prevent damage to the boot.
- Using the alignment marks (D) made during disassembly as a guide, install the spider assembly (A) and retainer ring (B) on the driveshaft splines (C).
- Add specified grease to the joint boot as much as it was wiped away at inspection.
- Install the both boot band.
- Using the SST (09495-3K000), secure the TJ boot bands. Clearance (A): 2.0 mm (0.0787 in.) or less
- Install the front driveshaft. Refer to «FRONT DRIVESHAFT»(/hyundai/santa-fe/iii-2012-2016/remont/driveshaft-universal-joints/#driveshaft-assembly) .
- Check the front alignment. Refer to «FRONT ALIGNMENT»(/hyundai/santa-fe/iii-2012-2016/remont/suspension-front/#front-suspension-system-wheel-alignment) .
Scheme 31
Scheme 32
Scheme 33
Scheme 34
- Remove the front driveshaft. Refer to «FRONT DRIVESHAFT»(/hyundai/santa-fe/iii-2012-2016/remont/driveshaft-universal-joints/#driveshaft-assembly) .
- Remove the TJ joint assembly. Refer to «TJ JOINT»(/hyundai/santa-fe/iii-2012-2016/remont/driveshaft-universal-joints/#driveshaft-assembly) .
- Remove the remove the both side of band (B) of the dynamic damper (A).
- Fix the driveshaft (A) with a vice (B) as illustrated.
- Apply soap powder on the shaft to prevent being damaged between the shaft spline and the dynamic damper when the dynamic damper is removed.
- Separate the dynamic damper (A) from the shaft (B) carefully.
Scheme 35
- Apply soap powder on the shaft to prevent being damaged between the shaft spline and the dynamic damper.
- Install the dynamic damper.
- Install the dynamic damper band (A).
- Using the SST (09495-3K000), secure the TJ boot bands (B). Clearance (A): 2.0 mm (0.0787 in.) or less
- Install the TJ joint assembly. Refer to «TJ JOINT»(/hyundai/santa-fe/iii-2012-2016/remont/driveshaft-universal-joints/#driveshaft-assembly) .
- Install the front driveshaft. Refer to «FRONT DRIVESHAFT»(/hyundai/santa-fe/iii-2012-2016/remont/driveshaft-universal-joints/#driveshaft-assembly) .
- Check the front alignment. Refer to «FRONT ALIGNMENT»(/hyundai/santa-fe/iii-2012-2016/remont/suspension-front/#front-suspension-system-wheel-alignment) .
Scheme 36
Scheme 37
- Remove the front driveshaft. Refer to «FRONT DRIVESHAFT»(/hyundai/santa-fe/iii-2012-2016/remont/driveshaft-universal-joints/#driveshaft-assembly) .
- Remove the TJ joint assembly. Refer to «TJ JOINT»(/hyundai/santa-fe/iii-2012-2016/remont/driveshaft-universal-joints/#driveshaft-assembly) .
- Remove the Dynamic damper. Refer to «DYNAMIC DAMPER»(/hyundai/santa-fe/iii-2012-2016/remont/driveshaft-universal-joints/#driveshaft-assembly) .
- Using a plier or flat-tipped (-) screwdriver, remove the BJ boot bands (A).
- Remove the BJ boot.
- Install in the reverse order of removal. NOTE: Do not disassemble the BJ assembly. Special grease must be applied to the driveshaft joint. Do not substitute with another type of grease. The boot band should be replaced with a new one.
- Check the front alignment. Refer to «FRONT ALIGNMENT»(/hyundai/santa-fe/iii-2012-2016/remont/suspension-front/#front-suspension-system-wheel-alignment) .
