Description

Emissions Control System consists of three major systems.

The Crankcase Emission Control System prevents blow-by gas from releasing into the atmosphere. This system recycles gas back into the intake manifold (Closed Crankcase Ventilation Type).
The Evaporative Emission Control System prevents evaporative gas from releasing into the atmosphere. This system burns gas at appropriate engine operating condition after gathering it in the canister.
The Exhaust Emission Control System converts the three pollutants [hydrocarbons (HC), carbon monoxide (CO), and oxides of nitrogen (NOx)] into harmless substances by using the 3-way catalytic converter.

Purge Control Solenoid Valve (PCSV)

Item	Specification
Coil Resistance (ohms) [2.4 DOHC]	19.0 ~ 22.0 [20°C (68°F)]
Coil Resistance (ohms) [3.5 V6]	22.0 ~ 26.0 [20°C (68°F)]

PURGE CONTROL SOLENOID VALVE (PCSV) SPECIFICATIONS

Fuel Tank Pressure Sensor (FTPS)

PRESSURE AND VOLTAGE SPECFICATIONS

Canister Close Valve (CCV)

Item	Specification
Coil Resistance (ohms)	19.8 ~ 21.8 [20°C (68°F)]

COIL RESISTANCE SPECIFICATION

Item	Kgf.m	N.m
Positive crankcase ventilation valve installation [2.4 DOHC]	0.19 ~ 0.29	1.9 ~ 2.8
Positive crankcase ventilation valve installation [3.5 V6]	0.8 ~ 1.2	7.8 ~ 11.8
Canister installation bolt/nut	0.4 ~ 0.6	3.9 ~ 5.9

TIGHTENING TORQUES SPECIFICATIONS

Symptom	Suspect area
Engine will not start or struggle to start	Vapor hose damaged or disconnected
Engine struggles to start	Malfunction of the Purge Control Solenoid Valve
Rough idle or engine stalls	Vapor hose damaged or disconnected
Rough idle or engine stalls	Malfunction of the PCV valve
Rough idle	Malfunction of the Evaporative Emission Control System
Excessive oil consumption	Positive crankcase ventilation line clogged
