Variant Coding

The HECU is programmed with a variant code based on the vehicle powertrain configuration. This variant code is used to determine the appropriate ESC calculations. Variant code programming should be performed whenever an HECU is replaced.

Scheme 183

Scheme 183: Variant Coding
Scheme 183: Variant Coding

Scheme 184

Scheme 184: Procedure of Variant Coding
Scheme 184: Procedure of Variant Coding
  1. Install a PCM (ECM & TCM)/ESC normally.
  2. Connect the GDS to the data link connector located underneath the crash pad.
  3. Select vehicle name.
  4. Select ANTI-LOCK BRAKE SYSTEM.
  5. Select the variant coding.
  6. Ignition "ON" & Engine "OFF".
  7. Perform variant coding.
  8. Ignition "OFF" and then ignition "ON".
  9. The variant coding is completed. CAUTION: If the warning lamp (ESC, EBD, ABS) is illuminated, follow the "Variant coding" again.

Scheme 185

Scheme 185: Input and Output Diagram
Scheme 185: Input and Output Diagram

Scheme 186

Scheme 186: ESC Operation Mode
Scheme 186: ESC Operation Mode

Scheme 187

Scheme 187
Scheme 187
  1. STEP 1 The ESC analyzes the intention of the driver.
  2. STEP 2 It analyzes the movement of the ESC vehicle.
  3. STEP 3 The HECU calculates the required strategy, then actuates the appropriate valves and sends torque control requests via CAN to maintain vehicle stability.

Scheme 188

Scheme 188: ESC Operation Mode
Scheme 188: ESC Operation Mode

Scheme 189

Scheme 189
Scheme 189

Scheme 190

Scheme 190
Scheme 190

Scheme 191

Scheme 191
Scheme 191
  1. ESC Non-operation-Normal braking. ESC OPERATION MODE Inlet valve (IV) Outlet valve (OV) Traction Control Valve (TCV) High pressure switch valve (HSV) Return pump Normal braking Open Close Open Close OFF NOTE: IV : Inlet Valve OV : Outlet Valve RL : Rear left wheel FR : Front right wheel FL : Front left wheel RR : Rear right wheel RP : Return pump TCV : Traction Control Valve HSV : High pressure Switch Valve
  2. ESC Increase Mode ESC INCREASE MODE Inlet valve (IV) Outlet valve (OV) Traction Control Valve (TCV) High pressure switch valve (HSV) Return pump Normal braking Open Close Close (Partial) Open ON (Motor s control) NOTE: IV : Inlet Valve OV : Outlet Valve RL : Rear left wheel FR : Front right wheel FL : Front left wheel RR : Rear right wheel RP : Return pump TCV : Traction Control Valve HSV : High pressure Switch Valve
  3. ESC Hold Mode (FR is only controlled.) ESC HOLD MODE Inlet valve (IV) Outlet valve (OV) Traction Control Valve (TCV) High pressure switch valve (HSV) Return pump Normal braking Close Close Close (Partial) Open OFF NOTE: IV : Inlet Valve OV : Outlet Valve RL : Rear left wheel FR : Front right wheel FL : Front left wheel RR : Rear right wheel RP : Return pump TCV : Traction Control Valve HSV : High pressure Switch Valve
  4. ESC Decrease Mode (FR is only controlled) ESC DECREASE MODE Inlet valve (IV) Outlet valve (OV) Traction Control Valve (TCV) High pressure switch valve (HSV) Return pump Normal braking Close Open Close (Partial) Open ON (Motor s low control) NOTE: IV : Inlet Valve OV : Outlet Valve RL : Rear left wheel FR : Front right wheel FL : Front left wheel RR : Rear right wheel RP : Return pump TCV : Traction Control Valve HSV : High pressure Switch Valve
