General - Wheel Alignment Hyundai Santa Fe I

Suspension 7 illustrations ~388 words

FRONT SUSPENSION SYSTEM MACPHERSON STRUT TYPE WITH COIL

Coil spring free height and identification color

ModelFree height mm (in)Identification color
SIRIUS 2.4L 2WD M/T398.7 (15.7)Green - Red
A/C + ABS A/C + S/R S/R + ABS407.6 (16.0)Green - Yellow
A/T407.6 (16.0)Green - Yellow
DELTA (V6) 2.7L
2WD A/T407.6 (16.0)Green - Yellow
4WD A/T416.9 (16.4)Green - White
SIGMA (V6) 3.5L
2WD A/T401.3 (15.8)Yellow - Yellow
4WD A/T397.1 (15.6)White - White

FRONT SUSPENSION SYSTEM GENERAL SPECIFICATIONS

  1. M/T: Manual Transmission
  2. A/T: Automatic Transmission
  3. A/C: Air Conditioner
  4. S/R: Sun Roof
  5. ABS: Anti-Lock Brake System

Shock absorber

Type: Gas pressurized type

Stroke mm (in): 169 (6.65)

Identification mark: LH 1, RH 2

Damping force at piston speed 0.3 m/s

[ 2.4L, 2.7L ]

Expansion N (kg)

870-130 (87-13)

Compression N (kg)

590-110 (59-11)

[3.5L]

Expansion N (kg)

950-140 (95-14)

Compression N (kg)

520-100 (52-10)

REAR SUSPENSION SYSTEM DOUBLE WISHBONE TYPE

Coil spring free height and identification color

ModelFree height mm (in)Identification color
2.4L, 2.7L2WD299.9 (11.8)Red - Yellow
4WD298.3 (11.7)Red - White
3.5L2WD297.4 (11.7)Yellow - Yellow
4WD302.8(11.9)White - White

REAR SUSPENSION SYSTEM GENERAL SPECIFICATIONS

Shock absorber

Type: Gas pressurized type

Stroke mm (in): 219 (8.62)

Identification color: Yellow 2

Damping force at piston speed 0.3 m/s

[2.4L, 2.7L]

Expansion N (kg)

630 +/-100 (63 +/-10)

Compression N (kg)

280+/-60 (28+/-6)

[3.5L]

Expansion N (kg)

690 +/-110 (69 +/-11)

Compression N (kg)

270 +/-60 (27 +/-6)

Wheel and Tire

Wheel type

Wheel size

Tire size

Tire inflation pressure kPa (psi)

Aluminum

6.5J x 16

225/70R 16

206 (30)

SERVICE STANDARD

ItemStandard value
FrontRear
Toe-in2 +/- 2mm (-0.08 +/- 0.08 in) (Standard diameter of tire: diameter 702mm) Max. difference 3mm0 +/- 2mm (0 +/- 0.08 in) (Standard diameter of tire: diameter 702mm) Max. difference 3mm
Camber0° +/- 30' (Max. difference between LH and RH: 30')0° +/- 30' (Max. difference between LH and RH: 45')
Caster2°30' +/- 30' (Max. difference between LH and RH: 30')
King pin angle12.59°
Side slip3 ~ +3mm (Forward 1m)
Wheel runout
Radial Axial0.3mm (0.012 in) 0.3mm (0.012 in)
LH: Left hand side RH: Right hand side

SERVICE STANDARD

TIGHTENING TORQUE

ItemNmKgf.mLbf.ft
Wheel nut90 ~ 1109 ~ 1167 ~ 81
Driveshaft nut200 ~ 26020 ~ 26148 ~ 192
Lower arm ball joint self - locking nut100 ~ 12010 ~ 1274 ~ 88
Lower arm bushing (A) to sub - frame mounting bolt100 ~ 12010 ~ 1274 ~ 88
Lower arm bushing (G) to sub - frame mounting bolt100 ~ 12010 ~ 1274 ~ 88
Front strut lower mounting nut100 ~ 12010 ~ 1274 ~ 88
Front strut upper mounting nut45 ~ 604.5 ~ 633 ~ 44
Front strut self - locking nut60 ~ 706 ~ 744 ~ 52
Stabilizer link assembly mounting nut100 ~ 12010 ~ 1274 ~ 88
Stabilizer bar bracket mounting bolt45 ~ 554.5 ~ 5.533 ~ 41
Sub - frame to body mounting bolt160 ~ 20016 ~ 20118 ~ 148
Rear shock absorber upper mounting nut (1)20 ~ 302 ~ 315 ~ 22
Rear shock absorber lower mounting bolt (1)120 ~ 14012 ~ 1488 ~ 103
Rear suspension upper/lower arm to knuckle mounting100 ~ 11010 ~ 1174 ~ 81
Rear suspension arm cam bolt (1)140 ~ 16014 ~ 16103 ~ 118
Crossmember to body mounting bolt140 ~ 16014 ~ 16103 ~ 118
Brake tube nut13 ~ 171.3 ~ 1.710 ~ 13
Tie rod end to knuckle24 ~ 342.4 ~ 3.418 ~ 25
Tie rod end lock nut50 ~ 555 ~ 5.537 ~ 41
Rear flange nut200 ~ 26020 ~ 26148 ~ 192
Rear hub mounting80 ~ 908 ~ 959 ~ 67
Rear suspension arm complete mounting (1)160 ~ 18016 ~ 18118 ~ 133
Rear shock absorber to knuckle mounting140 ~ 16014 ~ 16103 ~ 108
(1) Indicates parts which should be temporarily tightened, and then fully tightened with the vehicle on the ground in an unladen condition.
(1)

TIGHTENING TORQUE

CAUTIONReplace the self-locking nuts with new ones after removal.

SPECIAL TOOLS

SPECIAL TOOLS SPECIFICATIONS Tool (Number and Name) Illustration Use 09216-121000 Mounting bushing remover and installer Removal and installation of the front upper arm bushing and lower arm bushing (Used with 09551-31000) 09216-21300 Mounting bushing remover and installer Removal and installation of the trailing arm bushing (Used with 09552-38100) 09529-21000 Wheel alignment gauge attachment Measurement of the wheel alignment 09532-11600 Preload socket Measurement of the stabilizer bar link ball joint preload (Used with torque wrench) 09532-3A000 Preload socket Measurement of the front lower arm ball joint preload (Used with torque wrench) 09545-28100 Lower arm bushing remover and installer Removal and installation of the rear upper arm bushing and lower arm bushing (Used with 09552-25000) 09551-31000 Upper arm bushing remover and installer Removal and installation of the front lower arm bushing (Used with 09216-21000) 09552-25000 Suspension bushing remover and installer Removal and installation of the rear upper arm bushing and lower arm bushing (Used with 09545-28100) 09552-38100 Trailing arm bushing remover and installer Removal and installation of rear trailing arm bushing (Used with 09216-21300) 09546-26000 Strut spring compressor Compression of the coil spring

Scheme 1

Scheme 1: SPECIAL TOOLS

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

TROUBLESHOOTING

Trouble symptomProbable causeTrouble symptom
Hard steeringImproper front wheel alignmentCorrect
Excessive turning resistance of lower arm ball jointReplace
Flat tireAdjust
No power assistRepair or replace
Poor return of steering wheel to centerImproper front wheel alignmentCorrect
Poor ride qualityImproper front wheel alignmentCorrect
Damaged shock absorberRepair or replace
Broken or worn stabilizerReplace
Broken or worn coil springReplace
Worn lower arm bushingReplace
Improper tire inflation pressureCorrect
Abnormal tire wearImproper front wheel alignmentCorrect
Worn shock absorberReplace
WanderingImproper front wheel alignmentCorrect
Poor turning resistance of lower arm ball jointRepair
Loose or worn lower arm bushingReplace
Vehicle pulls to one sideImproper front wheel alignmentCorrect
Excessive turning resistance of lower arm ball jointReplace
Broken or worn coil springReplace
Bent lower armReplace
Steering wheel shimmyImproper front wheel alignmentCorrect
Excessive turning resistance of lower arm ball jointReplace
Broken or worn stabilizerReplace
Worn lower arm bushingReplace
Worn of shock absorberReplace
Broken or worn coil springReplace
BottomingBroken or worn springReplace
Malfunction of shock absorberReplace
Abnormal soundLoose partsRetighten
Damaged or worn wheel bearingsReplace
Faulty shock absorberReplace damaged parts
Defective tireReplace
Poor ride controlExcessive tire pressureAdjust pressure
Faulty shock absorberReplace
Loose wheel nutsTighten to specified torque
Sagging or broken coil springReplace
Vehicle body tilts to one sideDefective tireReplace
Worn bushingReplace
Deformation of driveshaft and arm assemblyReplace
Sagging or broken coil springReplace

TROUBLESHOOTING CHART
