Car Wiring Diagrams for Backup lamps circuit for Hyundai Kona I (2017-2021)

2.0L B+2 FUSE B-CAN HIGH B-CAN LOW B/UP LP BACKUP LAMP BACKUP SIG BLK WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM E/R JUNCTION BLOCK E/R-D ELECTROCHROMIC MIRROR ENGINE ROOM JUNCTION BLOCK GATEWAY GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START I/P-B I/P-D I/P-E I/P-G IPS 2 CTRL IPS CONTROL MODULE LEFT "C" PILLAR) LEFT REAR BUMPER LAMP MULTI FUSE 2 NCA WIRE ON/START INPUT ORG/ WIRE P-CAN HIGH P-CAN LOW PCB BLOCK PCM (2.0L) PNK WIRE RED WIRE RIGHT REAR BUMPER LAMP TCM (1.6L TURBO) (LEFT SIDE OF DASH) TCU 2 FUSE TRANSAXLE RANGE SW SIG D TRANSAXLE RANGE SW SIG N TRANSAXLE RANGE SW SIG P TRANSAXLE RANGE SW SIG R TRANSAXLE RANGE SWITCH WHT WIRE YEL WIRE
