Body control modules — Body control module circuit Hyundai Kona I

Components on these wiring diagrams 43

Click a component to highlight it on every diagram it appears on.

• "P" Position Sw
• Acc/On In
• Anti-Lock Brakes, Exterior Lights Systems
• B-Can High
• B-Can Low
• Blade Position Sw In
• Crash Output
• Door Warning Sw
• Fog Lamp Sw Sig
• Front Washer Sw Sig
• Hdlp High Sw In
• Headlights, Interior Lights Systems
• Heating Module Pwr
• Heating Sw Ind
• Heating Sw Sig
• I/P-E
• I/P-F
• Ign Key Interlock Sw
• Int/Vol Sw
• Light Sw Sig
• Module 1 Fuse
• Module 2 Fuse
• Module 3 Fuse
• Module 6 Fuse
• On In
• P-Can High
• P-Can Low
• Pdw Buzzer Control
• Pdw Sens Pwr I/P
• Pdw Switch Ind
• Pdw Switch Mode
• Rear Defogger Sw In
• Rf Sig
• Right End Of Dash
• Safety Power Wdw Enable
• Shift Lock Solenoid
• Stop Lamp Sw
• Sunroof Open Signal
• Warning Systems
• Wheel Heating Pwr
• Wiper Switch Signal Front
• Wiper Switch Signal Rear
• Wiper/Washer, Headlights Systems
