Sun Roof: Overview Hyundai Genesis I рестайлинг

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

1. Disconnect the negative (-) battery terminal.
2. Open the sunglass case cover from the overhead console then remove the 2 screws holding the overhead console. Disconnect the switch connector (6P) and Map lamp connector (6P), and then remove the overhead console lamp.
3. Check for continuity between the terminals. If the continuity is not as specified, replace the sunroof switch.

Scheme 6

Scheme 7

1. Disconnect the negative (-) battery terminal.
2. Remove the overhead console then remove the sun roof motor mounting screws (3EA). And then remove the sunroof motor (A) after disconnecting the connector (10 Pin).
3. Ground the terminals as below table, and check that the sunroof unit operates as below table.
4. Make these input tests at the connector if any test indicates a problem, find and correct the cause, then recheck the system. If all the input tests prove OK, the sunroof motor must be faulty; replace it. Terminal Test condition Test: Desired result 3 IG2 ON Check for voltage to ground: There should be battery voltage 1 Under all conditions Check for continuity to ground: There should be continuity. 6 Under all conditions Check for voltage to ground: There should be battery voltage.
