Cluster Module Diagnosis: Specifications Hyundai Genesis I рестайлинг

Specification

Fuel Level Sensor	Specification
Float Position	8/8	7/8	6/8	2/8	MIL ON
Fuel Level Sender A Resist. (ohms)	4	15.5	15.5	41	74.6
Fuel Level Senor B Resist. (ohms)	4	20.5	41.5	100	100
Quantity ( l )	74.5	64.3	56.2	23.7	11.6

Scheme 296: Diagnostic Circuit Diagram

Scheme 298: Scantool Data Analysis

Connect GDS.
IG "ON" and engine "OFF".
Select "DTC Analysis" mode.
After erase DTC, keep the vehicle condition within "the enable conditions" (Refer to " «DTC DETECTING CONDITION»(ref-590444-S00092808222013121700000) " table).
Is the same DTC occurred again? YES Go to next procedure. NO Fault is intermittent caused by poor contact in the sensor's and/or CLU's connector or was repaired and CLU memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590444-S14650067972013121700000) " procedure.

Scheme 299: Component Inspection

Check resistance of fuel level sender IG OFF. Disconnect fuel level sender A, B connectors. Measure resistance between both ends of fuel level sender A, B connectors with varying a float. Specification: 8 ohms (Full) ~ 200 ohms (Empty) depending on fuel level Are resistances within specifications? YES Go to next procedure. NO Substitute with a known - good unit and check for proper operation. If the problem is corrected, replace the unit and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590444-S14650067972013121700000) " procedure.
