Specification
| Items | Bulb Wattage (W) | |
|---|---|---|
| FRONT | Head lamp (High) | 55 |
| Head lamp (Low) | General: 55, HID: 35 | |
| Front turn signal lamp | 28 | |
| Front fog lamp | 35 | |
| Side marker | 5 | |
| Door mirror | LED | |
| REAR | Rear stop/tail lamp (Outside) | LED |
| Back up lamp | 16 | |
| Rear turn signal lamp | 21 | |
| License plate lamp | 5 | |
| High mounted stop lamp | LED | |
| Side marker | LED | |
| ROOM | Room lamp (Center/Side) | LED |
| Overhead console lamp | LED | |
| Foot lamp | 5 | |
| Glove box lamp | 5 | |
| Door courtesy lamp | 5 | |
Scheme 1
Scheme 2
Scheme 3
- Pull out the head lamp relay (Low) (A) from the engine compartment relay box. Head lamp (Low) relay
- Check for continuity between terminals. There should be continuity between the No. 87 and No. 30 terminals when power and ground are connected to the No. 86 and No. 85 terminals.
- There should be no continuity between the No. 87 and No. 30 terminals when power is disconnected.
Scheme 4
Scheme 5
Scheme 6
- Disconnect the negative (-) battery terminal.
- Loosen the mounting bolts (3EA) of head lamp. Remove the head lamp assembly (A) after disconnecting the lamp connectors. NOTE: Take care that retaining clip (A) is not to be damaged.
- Remove the bulb caps from the head lamp assembly. Head lamp high bulb cab Head lamp low bulb cab Turn signal bulb
