Air Conditioning System Diagnosis: Specifications Hyundai Genesis I рестайлинг

Automatic HVAC System 62 illustrations ~3769 words

Specification

*Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3 ± 0.15 V
Max. warm4.7 ± 0.15 V

Scheme 61

Scheme 61: Diagnostic Circuit Diagram

Scheme 62

Scheme 62: Monitor Scantool data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start Select "Air Mix Door Potentiometer-Passenger" parameter on the current data with scantool Perform Actuation Test for "Passenger Air Mix Door - 0%/50%/100%. With performing Actuation test, check that the value of Air Mix Door Potentiometer is changed and close to the value of Actuation Test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S17712837502013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S24547960842013121700000) " procedure.

*Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3 ± 0.15 V
Max. warm4.7 ± 0.15 V

Scheme 63

Scheme 63: Diagnostic Circuit Diagram

Scheme 64

Scheme 64: Monitor Scantool data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start Select "Air Mix Door Potentiometer-Passenger" parameter on the current data with scantool Perform Actuation Test for "Passenger Air Mix Door - 0%/50%/100%. With performing Actuation test, check that the value of Air Mix Door Potentiometer is changed and close to the value of Actuation Test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S04511211412013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S01438817422013121700000) " procedure.

*Voltage value of Intake potentiometer as a function of position of Intake door

Door positionVoltage
FRE0.3 ± 0.15 V
REC4.7 ± 0.15 V

Scheme 65

Scheme 65: Diagnostic Circuit Diagram

Scheme 66

Scheme 66: Monitor Scantool Data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start Select "Intake Potentiometer" parameter on the current data with scantool Perform Actuation Test for Air Inlet Mode Selection - Regulation/Fresh in order. With performing Actuation test, check that the value of each position sensors are changing. Specification: Recirculation: About 90%, Fresh: About 10%. Are the value of each position sensors changed when performing actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S02093019622013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S10591849452013121700000) " procedure.

*Voltage value of Intake potentiometer as a function of position of Intake door

Door positionVoltage
FRE0.3 ± 0.15 V
REC4.7 ± 0.15 V

Scheme 67

Scheme 67: Diagnostic Circuit Diagram

Scheme 68

Scheme 68: Monitor Scantool data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start Select "Intake Potentiometer" parameter on the current data with scantool Perform Actuation Test for Air Inlet Mode Selection - Regulation/Fresh in order. With performing Actuation test, check that the value of each position sensors are changing. Specification: Recirculation: About 90%, Fresh: About 10%. Are the value of each position sensors changed when performing actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S11870977482013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S28229142682013121700000) " procedure.

*Resistance value of in-car temp sensor as a function of temperature.

Temperature (°C/°F)Resistance (kohms)
20/-4285.6
10/14169
0/3297.7
10/5059.67
20/6837.4
30/8624.1
40/10415.9
50/12210.8

Scheme 69

Scheme 69: Diagnostic Circuit Diagram

Scheme 70

Scheme 70: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "In-car temperature sensor" parameter.
  4. Is the In-car temperature sensor normal? YES Go to " «INSPECTION AND REPAIR»(ref-590441-S19057477252013121700000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S33246208872013121700000) " procedure.

*Resistance value of in-car temp sensor as a function of temperature.

Temperature (°C/°F)Resistance (kohms)
20/-4285.6
10/14169
0/3297.7
10/5059.67
20/6837.4
30/8624.1
40/10415.9
50/12210.8

Scheme 71

Scheme 71: Diagnostic Circuit Diagram

Scheme 72

Scheme 72: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "In-car temperature sensor" parameter.
  4. Is the In-car temperature sensor normal? YES Go to " «INSPECTION AND REPAIR»(ref-590441-S30074300842013121700000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S11105124512013121700000) " procedure.

*Resistance value of ambient temp.sensor as a function of temperature.

Temperature (°C/°F)Resistance (kohms)
20/-4271.4
0/3295.1
25/7730
50/12211
60/1407.58

Scheme 73

Scheme 73: Diagnostic Circuit Diagram

Scheme 74

Scheme 74: Monitor Scantool Data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Ambient Air Temperature sensor" parameter.
  4. Is the ambient sensor normal? YES Go to " «INSPECTION AND REPAIR»(ref-590441-S15718786302013121700000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S08929857772013121700000) " procedure.

*Resistance value of ambient temp. sensor as a function of temperature.

Temperature (°C/°F)Resistance (kohms)
20/-4271.4
0/3295.1
25/7730
50/12211
60/1407.58

Scheme 75

Scheme 75: Diagnostic Circuit Diagram

Scheme 76

Scheme 76: Monitor Scantool Data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Ambient Air Temperature sensor" parameter.
  4. Is the ambient sensor normal? YES Go to " «INSPECTION AND REPAIR»(ref-590441-S07258764532013121700000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S27763575542013121700000) " procedure.

*Resistance value of evaporator sensor as a function of temperature.

Temperature (°C/°F)Resistance (kohms)
20/-443.3
0/3227.6
10/5018
20/6812.1
30/868.3
40/1045.8

Scheme 77

Scheme 77: Diagnostic Circuit Diagram

Scheme 78

Scheme 78: Monitor Scantool Data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Evaporator sensor" parameter on scantool.
  4. Is the Evaporator Sensor normal? YES Go to " «INSPECTION AND REPAIR»(ref-590441-S35295676992013121700000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S35317905422013121700000) " procedure.

*Resistance value of evaporator sensor as a function of temperature.

Temperature (°C/°F)Resistance (kohms)
20/-443.3
0/3227.6
10/5018
20/6812.1
30/868.3
40/1045.8

Scheme 79

Scheme 79: Diagnostic Circuit Diagram

Scheme 80

Scheme 80: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "Evaporator sensor" parameter on scantool. see scheme 1) Parameter of "Evaporator Sensor" will be fixed at -2°C (28.4°F), if there is any fault in Evaporator Sensor.
  4. Is the Evaporator Sensor normal? YES Go to " «INSPECTION AND REPAIR»(ref-590441-S01573966382013121700000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S31289887092013121700000) " procedure.

*Voltage value of Air Mix potentiometer as a function of temp door position.

Door PositionVoltage
Max. cool0.3 ± 0.15 V
Max. warm4.7 ± 0.15 V

Scheme 81

Scheme 81: Diagnostic Circuit Diagram

Scheme 82

Scheme 82: Monitor Scantool Data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Air Mix Door Potentioner-Driver" parameter on scantool. Select and perform Actuation test Air Mix Door Potentioner-Driver - 0%/50%/100% in order. With performing Actuation test, check that the value of Air Mix Door Potentiometer follows is changed and close to the value of Actuation Test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S29730658582013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S40464481912013121700000) " procedure.

*Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3 ± 0.15 V
Max. warm4.7 ± 0.15 V

Scheme 83

Scheme 83: Diagnostic Circuit Diagram

Scheme 84

Scheme 84: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Air Mix Door Potentioner-Driver" parameter on scantool. Select and perform Actuation test Air Mix Door Potentioner-Driver - 0%/50%/100% in order. With performing Actuation test, check that the value of Air Mix Door Potentiometer follows is changed and close to the value of Actuation Test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S39173313252013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S03231964262013121700000) " procedure.

*Voltage value of potentiometer as a function of mode door position.

Mode Door PositionVoltage
VENT0.3 ± 0.15 V
BI-LEVEL1.4 ± 0.4 V
FLOOR2.5 ± 0.4 V
MIX3.6 ± 0.4 V
DEF4.7 ± 0.15 V

Scheme 85

Scheme 85: Diagnostic Circuit Diagram

Scheme 86

Scheme 86: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Direction Potention" parameter on scantool. Select and perform Actuation test Driver Mode Door - Face/Foot/Defrost in order. Check that the value of all the parameters are changed when performing the actuation test. Specification: Face - About below 10%, Foot: About 50%, Defrost: About 90%. Are all the parameters changed when performing Actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S18578094712013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S21282460142013121700000) " procedure.

*Voltage value of potentiometer as a function of mode door position.

Mode Door PositionVoltage
VENT0.3 ± 0.15 V
BI-LEVEL1.4 ± 0.4 V
FLOOR2.5 ± 0.4 V
MIX3.6 ± 0.4 V
DEF4.7 ± 0.15 V

Scheme 87

Scheme 87: Diagnostic Circuit Diagram

Scheme 88

Scheme 88: Monitor Scantool Data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Direction Potention" parameter on scantool. Select and perform Actuation test Driver Mode Door - Face/Foot/Defrost in order. Check that the value of all the parameters are changed when performing the actuation test. Specification: Face - About below 10%, Foot: About 50%, Defrost: About 90%. Are all the parameters changed when performing Actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S40717593022013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S42538062062013121700000) " procedure.

*Voltage value of AQS sensor as a function of position of operating condition.

Operating conditionVoltageNote
Right after IGN "ON"2.5 V ± 0.3 VStay at Pre-Position
Normal4.3 V ± 0.3 VIntake door: REC
Gas detected0.9 V ± 0.3 VIntake door: FRE

Preheating Time: (35 ± 2 sec.)

Scheme 89

Scheme 89: Diagnostic Circuit Diagram

Scheme 90

Scheme 90: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "AQS sensor" parameter on scantool.
  4. Is the AQS sensor normal? YES Go to " «INSPECTION AND REPAIR»(ref-590441-S25239571072013121700000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S19012909862013121700000) " procedure.

*Voltage value of AQS sensor as a function of position of operating condition.

Operating conditionVoltageNote
Right after IGN "ON"2.5 V ± 0.3 VStay at Pre-Position
Normal4.3 V ± 0.3 VIntake door: REC
Gas detected0.9 V ± 0.3 VIntake door: FRE

Preheating Time: (35 ± 2 sec.)

Scheme 91

Scheme 91: Diagnostic Circuit Diagram

Scheme 92

Scheme 92: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "AQS sensor" parameter on scantool. The current data in normal state.
  4. Is the AQS sensor normal? YES Go to " «INSPECTION AND REPAIR»(ref-590441-S08082587492013121700000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S28701008642013121700000) " procedure.

*Voltage value of AQS sensor as a function of position of operating condition.

Operating conditionVoltageNote
Right after IGN "ON"2.5 V ± 0.3 VStay at Pre-Position
Normal4.3 V ± 0.3 VIntake door: REC
Gas detected0.9 V ± 0.3 VIntake door: FRE

Preheating Time: (35 ± 2 sec.)

Scheme 93

Scheme 93: Diagnostic Circuit Diagram

Scheme 94

Scheme 94: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal engine temperature after engine starts.
  3. Select and monitor "AQS sensor" parameter on scantool. The current data in normal state.
  4. Is the AQS sensor normal? YES Go to " «INSPECTION AND REPAIR»(ref-590441-S05840897352013121700000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S09734826942013121700000) " procedure.

*Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
COOL1.18 ± 0.15 V
WARM3.82 ± 0.15 V

Scheme 95

Scheme 95: Diagnostic Circuit Diagram

*Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
COOL1.18 ± 0.15 V
WARM3.82 ± 0.15 V

Scheme 96

Scheme 96: Diagnostic Circuit Diagram

*Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
COOL1.18 ± 0.15 V
WARM3.82 ± 0.15 V

Scheme 97

Scheme 97: Diagnostic Circuit Diagram

*Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
COOL1.18 ± 0.15 V
WARM3.82 ± 0.15 V

Scheme 98

Scheme 98: Diagnostic Circuit Diagram

*Voltage changes according to Console switch position

Console SwitchVoltage
COOL0.3 ± 0.15 V
WARM4.7 ± 0.15 V

Scheme 99

Scheme 99: Diagnostic Circuit Diagram

Scheme 100

Scheme 100: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal temperature after engine starts
  3. Check that the value of Console temperature actuator and switch is changeable according to changing direction with switch. Specification: COOL Position: About below 5.5%. Warm Position: About 90%.
  4. Is the value of the Console air mix switch potentiometer normal? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S40205879362013121700000) " procedure. NO Go to " «INSPECTION AND REPAIR»(ref-590441-S15297746972013121700000) " procedure.

*Voltage changes according to Console switch position

Console SwitchVoltage
COOL0.3 ± 0.15 V
WARM4.7 ± 0.15 V

Scheme 101

Scheme 101: Diagnostic Circuit Diagram

Scheme 102

Scheme 102: Monitor Scantool Data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal temperature after engine starts
  3. Check that the value of Console temperature actuator and switch is changeable according to changing direction with switch. Specification: COOL Position: About below 5.5%. Warm Position: About 90%.
  4. Is the value of the Console air mix switch potentiometer normal? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S14542876992013121700000) " procedure. NO Go to " «INSPECTION AND REPAIR»(ref-590441-S35955265352013121700000) " procedure.

*Hz of Defogger sensor according to Humidity

(%RH)(Hz)
037.19
2036.4
4035.6
6034.8
8034
10033.2

Scheme 103

Scheme 103: Diagnostic Circuit Diagram

Scheme 104

Scheme 104: Monitor Scantool Data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal temperature after engine starts
  3. Select and monitor "Auto defogger humidity sensor" parameter on scantool. If the DTC related auto defogger sensor is set, Air conditioner control Module regards and controls humidity as 0%
  4. Is the defogger sensor normal? YES Go to " «INSPECTION & REPAIR»(ref-590441-S01031207532013121700000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S16576784852013121700000) " procedure.

*Hz of Defogger sensor according to Humidity

(%RH)(Hz)
037.19
2036.4
4035.6
6034.8
8034
10033.2

Scheme 105

Scheme 105: Diagnostic Circuit Diagram

Scheme 106

Scheme 106: Monitor Scantool data
  1. Connect scantool with diagnostic connector.
  2. Warm up the engine to normal temperature after engine starts
  3. Select and monitor "Auto defogger humidity sensor" parameter on scantool.
  4. Is the defogger sensor normal? YES Go to " «INSPECTION & REPAIR»(ref-590441-S17821259042013121700000) " procedure. NO This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S29705803482013121700000) " procedure.

*Voltage output according to Actuator position

Door positionVoltage
CLOSE (VENT, B/L)About 4.7 V
FLOORAbout 3.94 V
MIXAbout 3.29 V
OPEN (DEF)About 1 V

Scheme 107

Scheme 107: Diagnostic Circuit Diagram

Scheme 108

Scheme 108: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start Select and monitor "Auto defogger mode direction potentioner" parameter on current data Perform Actuation Test for "Auto Defogger Mode Door - 0% (close)/50%/100% (open)" in order. Check that the value of auto defogger mode actuator is changed with performing actuation test. Specification: 0% (close): About 90%, 50%: About 55%, 100% (open): About 20%. Does the value of auto defogger mode actuator follow the specification? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S03996991092013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S11856509262013121700000) " procedure.

*Voltage output according to Actuator position

Door PositionVoltage
CLOSE (VENT, B/L)About 4.7 V
FLOORAbout 3.94 V
MIXAbout 3.29 V
OPEN (DEF)About 1 V

Scheme 109

Scheme 109: Diagnostic Circuit Diagram

Scheme 110

Scheme 110: Monitor Scantool Data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start Select and monitor "Auto defogger mode direction potentioner" parameter on current data Perform Actuation Test for "Auto Defogger Mode Door -0% (close)/50%/100% (open)" in order. Check that the value of auto defogger mode actuator is changed with performing actuation test. Specification: 0% (close): About 90%, 50%: About 55%, 100% (open): About 20%. Does the value of auto defogger mode actuator follow the specification? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S19027800732013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S36588131942013121700000) " procedure.

*The voltage of auto defogger mode actuator in accordance with position

Door positionVoltage
CLOSE (VENT, B/L)About 4.7 V
FLOORAbout 3.94 V
MIXAbout 3.29 V
OPEN (DEF)About 1 V

Scheme 111

Scheme 111: Diagnostic Circuit Diagram

Scheme 112

Scheme 112: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start Select and monitor "Auto defogger mode actuator" parameter on current data Perform Actuation Test for "auto defogger actuator -0% (close)/50%/100% (open)" in order. Check that the value of auto defogger mode actuator is changed with performing actuation test. Specification: 0% (close): About 90%, 50%: About 55%, 100% (open): About 20%. Does the value of auto defogger mode actuator follow the specification? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S00479673972013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S24533258432013121700000) " procedure.

*Voltage value of Air Mix potentiometer as a function of temp door position.

Door PositionVoltage
Max. cool0.3 ± 0.15 V
Max. warm4.7 ± 0.15 V

Scheme 113

Scheme 113: Diagnostic Circuit Diagram

Scheme 114

Scheme 114: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Air Mix Door Potentioner-Driver" parameter on scantool. Select and perform Actuation test Air Mix Door Potentioner-Driver - 0%/50%/100% in order. Check that the value of all the parameters are changed when performing the actuation test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S40322624922013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S10435570322013121700000) " procedure.

*Voltage value of Intake potentiometer as a function of position of Intake door

Door positionVoltage
FRE0.3 ± 0.15 V
REC4.7 ± 0.15 V

Scheme 115

Scheme 115: Diagnostic Circuit Diagram

Scheme 116

Scheme 116: Monitor Scantool data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start Select "Intake Potentiometer" parameter on the current data with scantool Perform Actuation Test for Air Inlet Mode Selection - Regulation/Fresh in order. With performing Actuation test, check that the value of each position sensors are changing. Specification: Recirculation: About 90%, Fresh: About 10%. Are the value of each position sensors changed when performing actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S10625672242013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S39698506782013121700000) " procedure.

*Voltage value of potentiometer as a function of mode door position.

Mode Door PositionVoltage
VENT0.3 ± 0.15 V
BI-LEVEL1.4 ± 0.4 V
FLOOR2.5 ± 0.4 V
MIX3.6 ± 0.4 V
DEF4.7 ± 0.15 V

Scheme 117

Scheme 117: Diagnostic Circuit Diagram

Scheme 118

Scheme 118: Monitor Scantool data
  1. Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal engine temperature after engine starts. Select and monitor "Direction Potention" parameter on scantool. Select and perform Actuation test Driver Mode Door - Face/Foot/Defrost in order. Check that the value of all the parameters are changed when performing the actuation test. Specification: Face - About below 10%, Foot: About 50%, Defrost: About 90%. Are all the parameters changed when performing Actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S14632147352013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S22314473612013121700000) " procedure.

*Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
Max. cool0.3 ± 0.15 V
Max. warm4.7 ± 0.15 V

Scheme 119

Scheme 119: Diagnostic Circuit Diagram

Scheme 120

Scheme 120: Monitor Scantool data
  1. Check Actuation Test Connect scantool with diagnostic connector. Warm up the engine to normal temperature after engine start Select "Air Mix Door Potentiometer-Passenger" parameter on the current data with scantool Perform Actuation Test for "Passenger Air Mix Door - 0%/50%/100%. With performing Actuation test, check that the value of Air Mix Door Potentiometer is changed and close to the value of Actuation Test. Specification: Check that the value of Air Mix Door Potentiometer at current data should be close to the value of the actuation test. Does the value of current data follow in accordance with the each actuation test? YES This is a intermittent problem caused by poor contact of component or Control Unit Thoroughly check the looseness, poor connection, bent, corrosion, contamination, deformation or damage of connector. Repair or replace as necessary and then, go to " «VERIFICATION OF VEHICLE REPAIR»(ref-590441-S15972884402013121700000) " procedure. NO Go to " «INSPECTION/REPAIR»(ref-590441-S03672008362013121700000) " procedure.

*Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
COOL1.18 ± 0.15 V
WARM3.82 ± 0.15 V

Scheme 121

Scheme 121: Diagnostic Circuit Diagram

*Voltage value of Air Mix potentiometer as a function of temp door position.

Door positionVoltage
COOL0.3 ± 0.15 V
WARM4.7 ± 0.15 V

Scheme 122

Scheme 122: Diagnostic Circuit Diagram
