Airbag Modules & Clock Spring: Removal & Installation Hyundai Genesis I рестайлинг

Installation

1. Remove the ignition key from the vehicle.
2. Disconnect the battery negative cable from battery and wait for at least three minutes before beginning work.
3. Place a Passenger Airbag (PAB) on the crash pad and tighten the Passenger Airbag (PAB) mounting nuts. Tightening torque : 5.9 ~ 6.9 Nm (0.6 ~ 0.7 kgf.m, 4.3 ~ 5.0 lb.ft)
4. Install the heater duct to the crash pad.
5. Install the crash pad. (Refer to the «CRASH PAD»(ref-590392-S04150349602013121700000) )
6. Tighten the PAB mounting bolt. Tightening torque : 6.9 ~ 10.8 Nm (0.7 ~ 1.1 kgf.m, 5.1 ~ 8.0 lb.ft)
7. Connect the Passenger Airbag (PAB) harness connector to the SRS main harness connector.
8. Reinstall the glove box. (Refer to the «CRASH PAD»(ref-590392-S04150349602013121700000) )
9. Reconnect the battery negative cable.
10. After installing the Passenger Airbag (PAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

Front Side Airbag

Note. Do not open the lid of the side airbag cover. Use a new mounting nuts when you replace a side airbag. Make sure that the airbag assembly cover is installed properly. Improper installation may prevent the proper deployment.

Scheme 56

1. Remove the ignition key from the vehicle.
2. Disconnect the battery negative cable and wait for at least three minutes.
3. Place a Side Airbag (SAB) on the side airbag frame and tighten the side airbag mounting nuts (2EA). Tightening torque : 6.8 ~ 8.8 Nm (0.7 ~ 0.9 kgf.m, 5.1 ~ 6.5 lb.ft)
4. Install the new seatback cover. (Refer to the «FRONT SEAT»(ref-590398-S36294528882013121700000) )
5. Install the front seat assembly, and then connect the Side Airbag (SAB) harness connector.
6. Recline and slide the front seat forward fully, make sure the harness wires are not pinched of interfering with other parts.
7. Reconnect the battery negative cable.
8. After installing the Side Airbag (SAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.

1. Remove the ignition key from the vehicle.
2. Disconnect the battery negative cable and wait for at least three minutes.
3. Tighten the Curtain Airbag (CAB) mounting bolts. Tightening torque : 11.8 ~ 14.7 Nm (1.2 ~ 1.5 kgf.m, 8.7 ~ 10.9 lb.ft) CAUTION: Never twist the airbag module when installing it. If the module is twisted, airbag module may operate abnormally.
4. Connect the CAB connector.
5. Install the following parts. (Refer to the «INTERIOR»(ref-590396-S07643020942013121700000) ) Headliner, Front pillar trim Center pillar trim, Rear pillar trim
6. Reconnect the battery negative cable.
7. After installing the Curtain Airbag (CAB), confirm proper system operation: Turn the ignition switch ON; the SRS indicator light should be turned on for about six seconds and then go off.
