Front Back View Camera System: Overview Hyundai Genesis I

Warning System 6 illustrations ~140 words

Scheme 30

Scheme 30: Component Location
Scheme 30: Component Location

Scheme 31

Scheme 31: Circuit Diagram
Scheme 31: Circuit Diagram

Description

Back view camera will activate when the backup light is ON with the ignition switch ON and the shift lever in the R position.

This system is a supplemental system that shows behind the vehicle through the AV monitor while backing-up.

WARNINGThis system is a supplementary function only. It is the responsibility of the driver or always check the inside/outside rearview mirror and the area behind the vehicle before and while backing up because there is a dead zone that can't see through the camera.

Scheme 32

Scheme 32: Back View Camera
Scheme 32: Back View Camera

Scheme 33

Scheme 33
Scheme 33
  1. Remove the screws, clip and trunk lid trim in the trunk. (Refer to «TRUNK LID»(ref-345940-S29269814672009102300000) )
  2. Remove the trunk lid panel (B).
  3. Remove the back view camera (A) after removing the connector and screws (2EA).

Scheme 34

Scheme 34: Back View Camera Unit
Scheme 34: Back View Camera Unit

Scheme 35

Scheme 35
Scheme 35
  1. Disconnect the negative (-) battery terminal.
  2. Remove the trunk left trim in the trunk. (Refer to «TRUNK LID»(ref-345940-S29269814672009102300000) )
  3. Remove the back view camera unit (A) after removing the nuts (2EA) and connector.
  1. Install the back view camera.
  2. Install the trunk lid panel and trim.
