Engine Control System (Fuel System (G6DB/G6DA - Gsl 3.3/3.8)): Specifications

Engine Control System (Fuel System (G6DB/G6DA - Gsl 3.3/3.8)): Specifications Hyundai Genesis I

Specification

[Throttle Position Sensor (TPS)]

Throttle Angle(°)	Output Voltage (V)
Throttle Angle(°)	TPS1	TPS2
0	0.0	5.0
10	0.5	4.5
20	0.9	4.1
30	1.4	3.6
40	1.8	3.2
50	2.3	2.7
60	2.7	2.3
70	3.2	1.8
80	3.6	1.4
90	4.1	0.9
100	4.5	0.5
110	5.0	0.0

THROTTLE POSITION SENSOR SPECIFICATION

Scheme 19

Item	Sensor Resistance ( kohms )
TPS1	4.0 ~ 6.0 [20°C (68°F)]
TPS2	2.7 ~ 4.1 [20°C (68°F)]

THROTTLE POSITION SENSOR (TPS) RESISTANCE

[ETC Motor]

Item	Specification
Coil Resistance (ohms)	1.275 ~ 1.725 [20°C (68°F)]

ETC MOTOR SPECIFICATION

Scheme 20

Scheme 20: Circuit Diagram

Air Flow (kg/h)	Frequency (Hz)
12.6	2,617
18.0	2,958
23.4	3,241
32.4	3,653
43.2	4,024
57.6	4,399
72.0	4,704
108.0	5,329
144.0	5,897
198.0	6,553
270.0	7,240
360.0	7,957
486.0	8,738
666.0	9,644
900.0	10,590

AIR FLOW FREQUENCY TABLE

Scheme 21

Scheme 21: Circuit Diagram

Temperature		Resistance ( kohms )
°C	°F	Resistance ( kohms )
40	40	100.87
20	4	28.58
0	32	9.40
10	50	5.66
20	68	3.51
40	104	1.47
60	140	0.67
80	176	0.33

TEMPERATURE RESISTANCE

Scheme 22

Pressure (kPa)	Output Voltage (V)
20.0	0.79
46.66	1.84
101.32	4.0

MANIFOLD ABSOLUTE PRESSURE SENSOR (MAPS) VOLTAGE SPECIFICATION

Scheme 23

Scheme 24

Scheme 24: Circuit Diagram

Temperature		Resistance ( kohms )
°C	°F	Resistance ( kohms )
40	40	48.14
20	4	14.13 ~ 16.83
0	32	5.79
20	68	2.31 ~ 2.59
40	104	1.15
60	140	0.59
80	176	0.32

TEMPERATURE RESISTANCE

Scheme 25

Scheme 25: Circuit Diagram

Item	Specification
Coil Resistance (ohms)	630 ~ 770ohms [25°C (77°F)]
Air Gap (mm)	0.5 ~ 1.5

CRANKSHAFT POSITION SENSOR (CKPS) SPECIFICATION

Scheme 26

Scheme 26: Wave Form

Scheme 27

Scheme 27: Circuit Diagram

Item	Specification
Output Voltage (V)	High: 5.0V
Output Voltage (V)	Low: 0.7V
Air Gap (mm)	0.5 ~ 1.5

CAMSHAFT POSITION SENSOR (CMPS) SPECIFICATION

Scheme 28

Scheme 28: Circuit Diagram

Item	Specification
Capacitance (pF)	1,480 ~ 2,220

KNOCK SENSOR (KS) SPECIFICATION

Scheme 29

Scheme 29: Circuit Diagram

A/F Ratio (A)	Output Voltage (V)
RICH	0.75 ~ 0.92
LEAN	0.04 ~ 0.1

HEATED OXYGEN SENSOR (HO2S) VOLTAGE SPECIFICATION

Item	Specification
Heater Resistance (ohms)	8.1 ~ 11.1ohms [21° (69.8°F)]

HEATED OXYGEN SENSOR (HO2S) SPECIFICATION

Scheme 30

Scheme 30: Wave Form

Scheme 31

Scheme 31: Circuit Diagram

Temperature		Resistance ( kohms )
°C	°F	Resistance ( kohms )
40	40	52.15
20	4	16.52
0	32	6.0
20	68	2.45
40	104	1.11
60	140	0.54
80	176	0.29

CVVT OIL TEMPERATURE SENSOR (OTS) TEMPERATURE AND RESISTANCE

Scheme 32

Scheme 32: Circuit Diagram

Accelerator Position	Output Voltage (V)
Accelerator Position	APS1	APS2
C.T	0.58 ~ 0.93	0.29 ~ 0.46
W.O.T	3.85 ~ 4.35	1.93 ~ 2.18

ACCELERATOR POSITION SENSOR (APS) VOLTAGE SPECIFICATION

Scheme 33

Scheme 34

Scheme 34: Circuit Diagram

Pressure (kPa)	Output Voltage (V)
6.67	0.5
0	2.5
+6.67	4.5

FUEL TANK PRESSURE SENSOR (FTPS) VOLTAGE SPECIFICATION

Scheme 35

Scheme 36

Scheme 36: Circuit Diagram

Item	Specification
Coil Resistance (ohms)	11.4 ~ 12.6 [20°C (68 °F)]

INJECTOR SPECIFICATION

Scheme 37

Scheme 37: Circuit Diagram

Item	Specification
Coil Resistance (ohms)	19.0 ~ 22.0 [20°C (68 °F)]

PURGE CONTROL SOLENOID VALVE (PCSV) SPECIFICATION

Scheme 38

Scheme 38: Circuit Diagram

Item	Specification
Coil Resistance (ohms)	6.7 ~ 7.7 [20°C (68 °F)]

CVVT OIL CONTROL VALVE (OCV) SPECIFICATION

Scheme 39

Scheme 39: Circuit Diagram

Item	Specification
Coil Resistance (ohms)	30.0 ~ 35.0 [20°C (68 °F)]

VARIABLE INTAKE SOLENOID (VIS) VALVE SPECIFICATION

Scheme 40

Scheme 40: Circuit Diagram

Item	Specification
Coil Resistance (ohms)	23.0 ~ 26.0 (20°C)

CANISTER CLOSE VALVE (CCV) SPECIFICATION

Scheme 41

Scheme 41: Circuit Diagram
