Steering Column and Steering Shaft: Specifications — Steering Column and Steering Shaft — Steering Column

Steering Column and Steering Shaft: Specifications Hyundai Genesis I

Steering Column 2 illustrations ~122 words

Specification

Bat. Voltage	IG Key ON	ENG. ON
Bat. Voltage	Approx. 11.8 [V] ~ 12.5 [V]	Approx. 12.5 [V] ~ 14.5 [V]

VOLTAGE SPECIFICATIONS

Scheme 10: Diagnostic Circuit Diagram

Scheme 11: Monitor Scantool Data

Connect scan tool to data link connector (DLC).
Engine "ON", Head light "ON", Defogger S/W "ON".
Monitor the "Supply voltage" parameter on the scan-tool.
Keep the 2500 Engine r.p.m with for 3 minutes and check the "Supply voltage" parameter on the scan-tool. Specification: below 16 [V]
Is parameter displayed within specifications? YES Fault is intermittent caused by poor contact in the sensor's and/or MPU's connector or was repaired and MPU memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-345928-S37839958862009102300000) " procedure. NO Go to Inspection/Repair procedure

Bat. Voltage	IG Key ON	ENG. ON
Bat. Voltage	Approx. 11.8[V] ~ 12.5[V]	Approx. 12.5 [V] ~ 14.5 [V]

VOLTAGE SPECIFICATIONS
