Ignition System (Engine Electrical System (G6DB/G6DA - Gsl 3.3/3.8)): Overview Hyundai Genesis I

Ignition System 8 illustrations ~350 words

Description

Ignition timing is controlled by the electronic control ignition timing system. The standard reference ignition timing data for the engine operating conditions are preprogrammed in the memory of the ECM (Engine Control Module).

The engine operating conditions (speed, load, warm-up condition, etc.) are detected by the various sensors. Based on these sensor signals and the ignition timing data, signals to interrupt the primary current are sent to the ECM. The ignition coil is activated, and timing is controlled.

Scheme 19

Scheme 19: Spark Test

Scheme 20

Scheme 20

Scheme 21

Scheme 21

Scheme 22

Scheme 22

Scheme 23

Scheme 23
  1. Remove the ignition coil connector (A). NOTE: When removing the ignition coil connector, pull the lock pin (A) and push the clip (B).
  2. Remove the ignition coil (A).
  3. Using a spark plug socket, remove the spark plug.
  4. Install the spark plug to the ignition coil.
  5. Ground the spark plug to the engine.
  6. Check if spark occurs while engine is being cranked. NOTE: To prevent fuel being Injected from injectors while the engine is being cranked, disconnect the fuel pump connector. Crank the engine for no more than 5-10 seconds.
  7. Inspect all the spark plugs.
  8. Using a spark plug socket, install the spark plug.
  9. Install the ignition coil.
  10. Reconnect the ignition coil connector. For FL group, refer to «FUEL DELIVERY SYSTEM (FUEL SYSTEM (G6DB/G6DA - GSL 3.3/3.8)) -- GENESIS»(ref-345904) .

Scheme 24

Scheme 24

Scheme 25

Scheme 25
  1. Remove the ignition coil connector (A). NOTE: When removing the ignition coil connector, pull the lock pin (A) and push the clip (B).
  2. Remove the ignition coil (A).
  3. Using a spark plug socket, remove the spark plug. CAUTION: Be careful that no contaminates enter through the spark plug holes.
  4. Inspect the electrodes (A) and ceramic insulator (B). Inspection Of Electrodes ELECTRODES INSPECTION TABLE Condition Dark deposits White deposits Description Fuel mixture too rich Low air intake Fuel mixture too lean Advanced ignition timing Insufficient plug tightening torque
  5. Check the electrode gap (A). Standard: 1.0 ~ 1.1 mm (0.0394 ~ 0.0433 in.)

Scheme 26

Scheme 26: Inspect Ignition Coil
  1. Measure the primary coil resistance between terminals (+) and (-). Standard value: 0.62ohms ± 10%
