Contents Wiring diagrams Section: Ignition Switch/steering Lock All sections

Button Engine Start System: Removal & Installation Hyundai Genesis I

Ignition Switch/steering Lock 17 illustrations ~276 words

Installation

  1. Install the connector.
  2. Install the start/stop button.
  3. Install the crash pad lower panel.

Scheme 3

Scheme 3: Component

Scheme 4

Scheme 4: Removal

Scheme 5

Scheme 5

Scheme 6

Scheme 6
  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad lower panel (A). (Refer to " «CRASH PAD»(ref-345931-S27758735332009102300000) ")
  3. Remove the connector (A).
  4. Remove the Fob holder assembly (A) after loosening the mounting screw.
  1. Install the fob holder assembly.
  2. Install the crash pad lower panel.

Scheme 7

Scheme 7: Component

Scheme 8

Scheme 8

Scheme 9

Scheme 9
  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad lower panel (A). (Refer to " «CRASH PAD»(ref-345931-S27758735332009102300000) ")
  3. Disconnect the electronic steering column lock connector (A).
  4. Remove the electronic steering column lock (A). (Refer to «STEERING COLUMN & SHAFT»(ref-345928) )
  1. Install the electronic steering column lock.
  2. Install the crash pad lower panel.

Scheme 10

Scheme 10: Component

Scheme 11

Scheme 11: System circuit diagram

Scheme 12

Scheme 12
  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad lower panel (A). (Refer to " «CRASH PAD»(ref-345931-S27758735332009102300000) ")
  3. Remove the reinforcing panel (A).
  4. Remove the power distribution module (A) after loosening a bolt and nut.
  1. Install the power distribution module.
  2. Install the crash pad lower panel.

Scheme 13

Scheme 13: PDM Diagnosis With Scan Tool

Scheme 14

Scheme 14

Scheme 15

Scheme 15

Scheme 16

Scheme 16

Scheme 17

Scheme 17

Scheme 18

Scheme 18

Scheme 19

Scheme 19
  1. It will be able to diagnose defects of Smart key with scan tool quickly. Scan tool can operates actuator forcefully, input/output value monitoring and self diagnosis.
  2. Select model and "Body control module" menu if you want to check PDM.
  3. Select "PDM" in the menu.
  4. Select Input/output monitoring", if you want to check current data of PDM. It provides the input/output status of each module.
  5. If you want to check PDM data operation forcefully, select "Actuation test".
