Specification
| Items | Bulb Wattage (W) | |
|---|---|---|
| FRONT | Head lamp (High) | 55 |
| Head lamp (Low) | General: 55, HID : 35 | |
| Front turn signal lamp | 28 | |
| Front fog lamp | 35 | |
| Side marker | 5 | |
| Door mirror | LED | |
| REAR | Rear stop/tail lamp (Outside) | LED |
| Back up lamp | 16 | |
| Rear turn signal lamp | 21 | |
| License plate lamp | 5 | |
| High mounted stop lamp | LED | |
| Side marker | LED | |
| ROOM | Room lamp (Center/Side) | LED |
| Overhead console lamp | LED | |
| Foot lamp | 5 | |
| Glove box lamp | 5 | |
| Door courtesy lamp | 5 | |
LIGHTING SYSTEM SPECIFICATION
Scheme 1
Scheme 2
Scheme 3
- Pull out the head lamp relay (Low) (A) from the engine compartment relay box. Head lamp (Low) relay
- Check for continuity between terminals. There should be continuity between the No.87 and No.30 terminals when power and ground are connected to the No. 86 and No.85 terminals.
- There should be no continuity between the No.87 and No.30 terminals when power is disconnected.
Scheme 4
Scheme 5
Scheme 6
- Disconnect the negative (-) battery terminal.
- Loosen the mounting bolts (3EA) of head lamp. Remove the head lamp assembly (A) after disconnecting the lamp connectors. NOTE: Take care that retaining clip (A) is not to be damaged.
- Remove the bulb caps from the head lamp assembly. Head lamp high bulb cab Head lamp low bulb cab Turn signal bulb
