Speaker Hyundai Genesis I

Audio System 36 illustrations ~548 words

Speaker

ModelGeneralPremiumDIS
ItemInput PowerSpeaker Impedance (ohms)Input PowerSpeaker Impedance (ohms)Input PowerSpeaker Impedance (ohms)
Front doorDoor speaker25W2 ± 0.325W2 ± 0.325W2 ± 0.3
MAX50WMAX50WMAX50W
Tweeter speaker25W3.4 ± 0.58 Vrms3.68 Vrms3.6
MAX 50W
Middle speaker8 Vrms1.9 ± 0.25
Rear doorDoor speaker25W2 ± 0.325W2 + 0.325W2 ± 0.3
MAX 50WMAX 50WMAX 50W
Tweeter speaker8 Vrms3.68 Vrms3.6
Center speaker8Vrms2.15 ± 0.258 Vrms2.15 ± 0.25
Sub woofer speaker25W2 ± 0.316 Vrms4.8 ± 116 Vrms4.8 ± 1
MAX 50W
Surround speaker8 Vrms2.15 ± 0.258 Vrms2.15 ± 0.25
Center tweeter speaker8 Vrms3.6
Speaker Number7EA14 EA17 EA

SPEAKER REFERENCE CHART

Scheme 10

Scheme 10: Components
Scheme 10: Components

Scheme 11

Scheme 11: Components
Scheme 11: Components

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16: Audio Unit
Scheme 16: Audio Unit

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22
  1. Disconnect the negative (-) battery terminal.
  2. Remove the crash pad lower panel (A).
  3. Remove the connector (A).
  4. Remove the mounting screws and then remove the audio unit (A).
  5. Remove the connector (A). NOTE: When the compact disc is not ejected, do not remove it forcibly
  6. When separate the CD ROM drive, if necessary, remove the screws (5EA) on the head unit.
  7. Remove the connector (A).
  8. Remove the CD ROM drive (A).

Scheme 23

Scheme 23: Keyboard Unit
Scheme 23: Keyboard Unit

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26
  1. Disconnect the negative (-) battery terminal.
  2. Remove the cluster fascia panel. (Refer to «CRASH PAD»(ref-345931-S27758735332009102300000) ))
  3. Remove the crash pad side garnish (A) after removing the screws.
  4. Remove the center fascia panel (A) after removing the screws.
  5. Remove the connectors (A).
  6. Remove the keyboard unit (A) after removing the screws.

Scheme 27

Scheme 27: Monitor Unit
Scheme 27: Monitor Unit

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29
  1. Disconnect the negative (-) battery terminal.
  2. Remove the cluster fascia panel. (Refer to «CRASH PAD»(ref-345931-S27758735332009102300000) ))
  3. Remove the crash pad side garnish (A) after removing the screws.
  4. Remove the center fascia panel (A) after removing the screws.
  5. Remove the connectors (A).
  6. Remove the monitor unit (A) after removing the screws.
  1. Install the audio head unit after connecting the connectors.
  2. Install the crash pad lower panel and connectors.
  3. Connect the negative (-) battery terminal.
  1. Install the keyboard unit after connecting the connectors.
  2. Install the center fascia panel.
  3. Install the crash pad side garnish, cluster fascia panel and crash pad lower panel.
  1. Install the monitor unit after connecting the connectors.
  2. Install the center fascia panel.
  3. Install the crash pad side garnish, cluster fascia panel and crash pad lower panel.

Scheme 30

Scheme 30: Front Speaker
Scheme 30: Front Speaker
  1. Remove the front door trim panel (Refer to «FRONT DOOR»(ref-345940-S05482049952009102300000) ).
  2. Remove the front speaker (A) after removing 4 rivets.

Scheme 31

Scheme 31: Rear Speaker
Scheme 31: Rear Speaker
  1. Remove the rear door trim panel (Refer to «REAR DOOR»(ref-345940-S32211081522009102300000) ).
  2. Remove the rear speaker (A) after removing 4 rivets.

Scheme 32

Scheme 32: Front Door Tweeter Speaker
Scheme 32: Front Door Tweeter Speaker

Scheme 33

Scheme 33
Scheme 33
  1. Remove the front door delta cover (A) after disconnecting the connector (B). (Refer to «FRONT DOOR»(ref-345940-S05482049952009102300000) )
  2. Remove the tweeter speaker (A).

Scheme 34

Scheme 34: Front Door Middle Speaker
Scheme 34: Front Door Middle Speaker

Scheme 35

Scheme 35
Scheme 35
  1. Remove the front door trim panel (A). (Refer to «FRONT DOOR»(ref-345940-S05482049952009102300000) )
  2. Remove the middle speaker (A) after removing the screws.

Scheme 36

Scheme 36: Rear Door Tweeter Speaker
Scheme 36: Rear Door Tweeter Speaker

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38
  1. Remove the rear door trim panel (A). (Refer to «REAR DOOR»(ref-345940-S32211081522009102300000) ).
  2. Remove the door trim garnish (A) after removing the screws inside the door trim panel.
  3. Remove the tweeter speaker (A) after removing the screws and connectors.

Scheme 39

Scheme 39: Crash Pad Center Speaker
Scheme 39: Crash Pad Center Speaker

Scheme 40

Scheme 40
Scheme 40
  1. Remove the crash pad center speaker grill (A).
  2. Remove the crash pad center speaker (A) after loosening the mounting screws (3EA).

Scheme 41

Scheme 41: Sub Woofer Speaker
Scheme 41: Sub Woofer Speaker

Scheme 42

Scheme 42
Scheme 42
  1. Remove the rear seat (Refer to «REAR SEAT»(ref-345934-S22143421002009102300000) ).
  2. Remove the rear package tray (A) (Refer to «REAR SEAT»(ref-345934-S22143421002009102300000) ).
  3. Remove the sub woofer speaker (A) after removing bolts (3EA).

Scheme 43

Scheme 43: Surround Speaker
Scheme 43: Surround Speaker

Scheme 44

Scheme 44
Scheme 44
  1. Remove the rear seat (Refer to «REAR SEAT»(ref-345934-S22143421002009102300000) ).
  2. Remove the rear package tray (A) (Refer to «REAR SEAT»(ref-345934-S22143421002009102300000) ).
  3. Remove the surround speaker (A) after removing bolts (2EA).

Scheme 45

Scheme 45: External Amp
Scheme 45: External Amp
  1. Disconnect the negative (-) battery terminal.
  2. Remove the right trunk side trim.
  3. Remove the external amplifier (A) after removing nuts and connectors.
