Esc (Electronic Stability Control) System: Specifications Hyundai Genesis I

Anti-Lock/traction Control 9 illustrations ~196 words

Specifications

Normal Voltage RangeIGN "ON" or Engine "ON"
10V ~ 16V

Scheme 1

Scheme 1: Diagnostic Circuit Diagram
Scheme 1: Diagnostic Circuit Diagram

Scheme 2

Scheme 2: Monitor Scantool Data
Scheme 2: Monitor Scantool Data
  1. Connect scantool to Data Link Connector(DLC).
  2. IG ON or Engine ON
  3. Monitor the "BATTERY VOLTAGE" parameter on the scantool. Specification: Below 17.0V see scheme 1) Normal data at the idle state
  4. Is the battery voltage normal? YES Fault is intermittent caused by poor connection in power harness (IGN+) and/or HECU's connector or was repaired and HECU memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration, or damage. Repair or replace as necessary and then go to " «VERIFICATION OF VEHICLE REPAIR»(ref-345903-S27853773362009102300000) " procedure. NO Go to " «TERMINAL AND CONNECTOR INSPECTION»(ref-345903-S42263662592009102300000) " procedure.
Normal Voltage RangeIGN "ON" or Engine "ON"
10V ~ 16V
Sensor TypeOutput VoltageTooth CountAirgap
HIGHLOW
Active Type14 mA7mA460.4~1.5mm

Scheme 3

Scheme 3: Diagnostic Circuit Diagram
Scheme 3: Diagnostic Circuit Diagram
Sensor TypeOutput VoltageTooth CountAirgap
HIGHLOW
Active Type14 mA7 mA460.4~1.5mm
Sensor TypeOutput VoltageTooth CountAirgap
HIGHLOW
Active Type14 mA7 mA460.4~1.5mm

Scheme 4

Scheme 4: Diagnostic Circuit Diagram
Scheme 4: Diagnostic Circuit Diagram
Sensor TypeOutput VoltageTooth CountAirgap
HIGHLOW
Active Type14 mA7 mA460.4~1.5mm
Sensor TypeOutput VoltageTooth CountAirgap
HIGHLOW
Active Type14 mA7 mA47 EA0.4~1.5mm

Scheme 5

Scheme 5: Diagnostic Circuit Diagram
Scheme 5: Diagnostic Circuit Diagram
Sensor TypeOutput VoltageTooth CountAirgap
HIGHLOW
Active Type14 mA7 mA47 EA0.4~1.5mm
Sensor TypeOutput VoltageTooth CountAirgap
HIGHLOW
Active Type14 mA7mA47 EA0.4~1.5mm

Scheme 6

Scheme 6: Diagnostic Circuit Diagram
Scheme 6: Diagnostic Circuit Diagram
Sensor TypeOutput VoltageTooth CountAirgap
HIGHLOW
Active Type14 mA7mA47 EA0.4~1.5mm
DescriptionSpecificationRemarks
Operating voltage8 ~ 16V
Current ConsumptionMax. 250mA
Operating temperature40 ~ 85°C
Yaw-rate sensor Measurement range75 ~ 75°/sec
Lateral G sensor Measurement range1.7gN ~ +1.7gN

Scheme 7

Scheme 7: External Diagram
Scheme 7: External Diagram

Scheme 8

Scheme 8: Replacement
Scheme 8: Replacement
  1. Turn ignition switch OFF and disconnect the negative (-) battery cable
  2. Remove the floor console. (Refer to the «CONSOLE»(ref-345931-S11458692682009102300000) )
  3. Disconnect the yaw rate & lateral G sensor connector.
  4. Remove the mounting bolts (A). Tightening torque: 6.9 ~ 8.8 Nm (0.7 ~ 0.9 kgf.m, 5.1 ~ 6.5 lb-ft)
  5. Installation is the reverse of removal.

Specification

DescriptionSpecification
Operating voltage8 ~ 16V
Operating temperature40 ~ 85°C
Current consumptionMax. 150mA
Measuring rangeAngle780 ~ 779.9°
Angular velocity0~1016°/sec

Scheme 9

Scheme 9: Circuit Diagram
Scheme 9: Circuit Diagram
