EGR System Hyundai Excel I

Testing & Diagnostics 5 illustrations ~479 words

The EGR system is used to reduce Oxides of Nitrogen (NOx) in the exhaust system. The exhaust gas is partially recirculated from an exhaust port at the cylinder head into a port located at the intake manifold below the carburetor. The EGR flow is controlled by an EGR control valve, a sub valve and a thermo valve. (Scheme 3)

Scheme 3

Scheme 3: EGR SYSTEM

EGR CONTROL VALVE

The EGR control valve is controlled by carburetor vacuum in response to throttle valve opening, while EGR flow is suspended at idle and wide open throttle operations. The thermo valve controls vacuum that is applied on the EGR control valve. (Scheme 4)

Scheme 4

Scheme 4: EGR CONTROL VALVE

SUB EGR CONTROL VALVE

The sub EGR control valve opens and closes in unison with the movement of the throttle valve due to a linkage. (Scheme 5) This is done to closely modulate EGR flow controlled by the EGR control valve in response to the throttle valve opening.

Scheme 5

Scheme 5: SUB EGR CONTROL VALVE

THERMO VALVE

The thermo valve in the EGR vacuum supply line is a switch that is sensitive to engine temperature. The thermo valve eliminates vacuum signal to the EGR valve during engine warm-up when less NOx is emitted. Less EGR helps maintain acceptable driveability. (Scheme 6)

Scheme 6

Scheme 6: THERMO VALVE

Scheme 7

Scheme 7: EGR SYSTEM
  1. Check vacuum hose for routing and installation. Start engine when cold and run at idle speed. Ensure increasing engine RPM (idle to 2500 RPM) does not cause EGR valve to operate. If EGR valve operates, replace thermo valve.
  2. Warm up engine to normal operating temperature 185-205°F (85-95°C). Ensure when engine is at 2500 RPM, EGR valve operates. If EGR valve does not operate, inspect EGR control valve or thermo valve.
  3. Disconnect Green striped hose from thermo valve. Connect a vacuum pump to thermo valve. Apply 10 in. Hg at thermo valve. If no vacuum is available, thermo valve is defective. Replace thermo valve. (Scheme 7)
  4. Remove vacuum pump from thermo valve and reconnect Green striped hose to thermo valve. Disconnect Green striped hose from nipple of carburetor and connect a vacuum pump to hose end.
  5. Open sub EGR valve by pulling it by hand. Using vacuum pump, apply 10 in. Hg. If idling speed becomes rough, then EGR valve is operating properly. If idling speed is unchanged, then valve is not operating. Replace EGR valve.
  6. Remove vacuum pump from Green striped hose end and reconnect Green striped hose to carburetor. Disconnect Yellow striped hose from EGR control valve. Connect a vacuum pump to nipple of EGR control valve.
  7. Operate sub EGR valve by pulling it by hand and apply minus 6 in. Hg with vacuum pump. If idling speed becomes rough or erratic, then EGR valve is operating properly.
  8. If idling speed remains unchanged, valve is not operating. Replace EGR valve. Remove vacuum pump from EGR control valve and reconnect Yellow stripe hose to nipple of EGR control valve.
